xStack DGS/DXS-3300 Series Layer 3 Stackable Gigabit Ethernet Switch CLI Manual
Traffic segmentation allows further sub-division of VLANs into smaller groups of ports that will help to reduce traffic on the
VLAN. The VLAN rules take precedence, and then the traffic segmentation rules are applied. The traffic segmentation
commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table.
Command
config traffic_segmentation
show traffic_segmentation
Each command is listed, in detail, in the following sections.
config traffic_segmentation
Purpose
Syntax
Description
Parameters
Restrictions
Example usage:
To configure ports 1 through 10 to be able to forward frames to port 11 through 15:
DGS-3324SRi:4# config traffic_segmentation 1
Command: config traffic_segmentation 1
Success.
DGS-3324SRi:4#
T
RAFFIC
Parameters
[<portlist> | all] forward_list [null | all | <portlist>]
{<portlist>}
Used to configure traffic segmentation on the Switch.
config traffic_segmentation [<portlist> | all] forward_list [null | all
| <portlist>]
The config traffic_segmentation command is used to configure
traffic segmentation on the Switch.
<portlist> − Specifies a range of ports that will be configured for traffic
segmentation. The port list is specified by listing the lowest switch
number and the beginning port number on that switch, separated by a
colon. Then the highest switch number, and the highest port number
of the range (also separated by a colon) are specified. The beginning
and end of the port list range are separated by a dash. For example,
1:3 specifies switch number 1, port 3. 2:4 specifies switch number 2,
port 4. 1:3-2:4 specifies all of the ports between switch 1, port 3 and
switch 2, port 4 − in numerical order.
all – Specifies all ports on the Switch.
forward_list − Specifies a port or range of ports that will receive
forwarded frames from the ports specified in the portlist, above.
null − No ports are specified
•
all – Specifies all ports on the Switch.
•
<portlist> − Specifies a range of ports for the forwarding list. This
•
list must be on the same switch previously specified for traffic
segmentation (i.e. following the <portlist> specified above for
config traffic_segmentation).
Only administrator-level users can issue this command.
S
EGMENTATION
1-1
10 forward_list 1
:
:
1-1
10 forward_list 1
:
:
238
26
C
OMMANDS
11-1
15
:
:
11-1
15
:
:
