The two Notch circuits may be enabled and/or dis-
abled using menu selection 2-9 . It is important to take
note of the selection options available:
IF NOTCH - Manual IF notch operation using the
front panel knob with the same name. The EDSP notch
is not accessible in this mode.
AUTO DSP - When EDSP is engaged (the green
"EDSP" LED is lit), the [ NOTCH ] button serves as an
On/Off switch for the EDSP auto-notch filter. The EDSP
notch filter automatically locates existing heterodynes
and notches them out. Any additional heterodynes are
also notched as they appear. The IF Notch is acces-
sible only when the EDSP is turned off.
SELECT - If EDSP is engaged ( menu selection 0-9
not set to "off"), and the [ NOTCH ] button is pressed,
both the EDSP Auto-Notch and IF notch operation take
effect simultaneously. If EDSP were disabled via menu
selection 0-9 , the IF Notch will still be available.
Note that there is a "short-cut" available, affording
easy access to menu selection 2-9 . Just press and hold
in the [ FAST ] key, and press the [ NOTCH ] button.
MARK-V FT-1000MP Operating Manual
Advanced Features
EDSP
Important Note About EDSP
An advantage of EDSP is the flexibility for the user
to customize or "tailor" received and transmitted
audio. Menu selections 4-4, 5-9, and 7-7 each have
distinct effects on the sound of your transmitted
audio. The "ultimate" combination of these settings
will of course vary between users personal taste,
and for the desired effect (distinctive audio, QRM
penetration, etc.).
The easiest way to immediately hear the effect of
different EDSP settings is to use the transceiver's
built-in MONITOR circuit to listen to your audio while
transmitting. In this way, you can step through the
various setting combinations, and select the ones
that appeal the most to you, or the receiving sta-
tion.
page 75
