User's Guide for Polycom HDX Room Systems

Showing, Moving, and Turning Off the PIP

Specifying When to Display the PIP

12
Your system may be configured to display a Picture-in-Picture (PIP) window.
During a call on a single-monitor system, the PIP displays what your main
camera is sending to the far site. If the far site shows any type of content, the
content appears in the main part of the screen, and the PIP changes to show the
people at the far site.
During a call on a dual-monitor system, what you see on each monitor and in
the PIP depends on how the Polycom HDX system has been configured.
To show, move, or turn off the PIP during a call:
Press Display on the remote control to display the PIP on screen.
•
• While the PIP has a yellow border, press
it to different corners of the screen.
After a brief pause, the PIP border turns blue. Then, press
•
turn the PIP off.
To swap the views shown in the PIP and the main screen:
1. If the PIP is not showing, press
display the PIP on screen.
2. Press Camera and select the
Your system may be configured with specific default behavior for the PIP in
calls. Depending on your system configuration, you can show, move, or hide
the PIP as needed after a call connects.
To specify when to display the PIP:
1. Select System from the Place a Call screen.
2. Select User Settings from the System screen.
3. Select Next to see more settings.
Display repeatedly to move
Display on the remote control to
Swap PIP icon.
Display to
© Polycom, Inc.
