SHB103 LAG1156 Full-Size SBC User's Manual
1.1

Specifications

CPU
Intel® Pentium® Desktop Processor(G6950),
Intel® Core™ i3 Desktop Processor,
Intel® Core™ i5 Desktop Processor,
Intel® Core™ i7-800 series Desktop Processor
System Chipset
®
Intel Q57
CPU Socket
LAG1156 Socket
DRAM Transfer Rate
1066/1333 MHz
BIOS
AMI BIOS via SPI interface with socket
System Memory
Two 240-pin DDR3 DIMM sockets
Maximum up to 8GB DDR3 memory
Supports DDR3 1066/1333 memory
L1, L2, L3 Cache: integrated in CPU
Onboard Multi-I/O
Parallel Port: one 26-pin 2.54-pitch box-header,
SPP/EPP/ECP supported
Serial Port: one for RS-232/422/485 with 10-pin, 2.54-pitch
box-header (COM1) and one port for RS-232 with 10-pin,
2.54-pitch box-header (COM2)
Floppy controller: one 34-pin, 2.54-pitch box-header
supports two drives (1.44MB for each)
USB Interface
Ten USB ports compliant with USB Spec. Rev. 2.0 (8 ports
on SHB103, 4 ports to SHB connector-C golden fingers)
