AXIOMTEK SHB103 Series User Manual page 109

64 GND a_PERn4
65 a_PETp5 GND
66 a_PETn5 GND
67 GND a_PERp5
68 GND a_PERn5
69 a_PETp6 GND
70 a_PETn6 GND
71 GND a_PERp6
72 GND a_PERn6
73 a_PETp7 GND
74 a_PETn7 GND
75 GND a_PERp7
76 GND a_PERn7
77 N.C GND
78 +3.3V +3.3V
79 +3.3V +3.3V
80 +3.3V +3.3V
81 +3.3V +3.3V
82 RSVD RSVD
X8 PCIe Connector B
Side B
1 +5Vaux +5Vaux
2 GND N.C
3 a_PETp8 GND
4 a_PETn8 GND
5 GND a_PERp8
6 GND a_PERn8
7 a_PETp9 GND
8 a_PETn9 GND
9 GND a_PERp9
10 GND a_PERn9
11 N.C GND
PICMG v1.3 Interface Definition
SHB103 LAG1156 Full-Size SBC User's Manual
Mechanical Key
64 GND
65 GND
66 GND
67 GND
68 GND
69 GND
70 GND
71 GND
72 GND
73 +12V
74 +12V
75 +12V
76 +12V
77 +12V
78 +12V
79 +12V
80 +12V
81 +12V
82 +12V
X8 PCIe Connector D
Side A Side B
1 INTB#
2 INTD#
3 GND
4 REQ3#
5 REQ2#
6 PCI_RST#
7 REQ1#
8 REQ0#
9 N.C
10 GND
11 N.C
GND
GND
GND
GND
GND
GND
GND
GND
GND
+12V
+12V
+12V
+12V
+12V
+12V
+12V
+12V
+12V
+12V
Side A
INTA#
INTC#
N.C
GNT3#
GNT2#
GNT1#
GNT0#
SERR#
+3.3V
N.C
GND
103
