VGA Controller
Chipset -- Intel
supports 3D, 2D, video capabilities
Memory Size -- Intel
memory for frame buffer option as OS option:
1. Windows XP:
* For Total System Memory < 1GB,
Graphics sharing memory = 128 MB Maximum;
* For 1 GB to 1.5 GB Total System Memory,
Graphics sharing memory = 512 MB Maximum;
* For 1.5 GB to 2 GB Total System Memory,
Graphics sharing memory = 768 MB Maximum;
* For 2 GB and Above Total System Memory,
Graphics sharing memory = 1GB Maximum.
2. Windows Vista:
* Graphics sharing memory max to 0.5* (OS Ram
Size – 512)
Resolution -- Analog output -- the analog port utilizes an
integrated 350MHz 24-bit RAMDAC that can directly drive a
standard progressive scan analog monitor up to a resolution
of 2048x1536 pixels with 32-bit color at 75 Hz
Analog Output Interface -- CRT from DAC output via 15-pin
D-Sub connector on the edge; CRT always ON supported
Ethernet
The LAN1/LAN2 are WG82578DM/WG82583V Ethernet
controller support 10/100/1000 Mb/s
Dual PCI-Express x1 LAN
Serial ATA
Support Serial ATA/Serial ATA II
Six Serial ATA-II ports, 3GB/s performance and SATA RAID
0/1/5/10 by Q57
Introduction
SHB103 LAG1156 Full-Size SBC User's Manual
®
integrated Graphics Gen5 on Intel
®
DVMT 5.0 supported; preallocated
®
Q57
