SHB103 LAG1156 Full-Size SBC User's Manual

4.1

The SHB103 Series supports Intel

™

Core

2 Duo/Celeron

system operated under Windows

environments. The system performance depends on the

microprocessor. Make sure all correct settings are arranged

for your installed microprocessor to prevent the CPU from

damages.

4.2

The SHB103 Series uses AMI Plug and Play BIOS with a

single 32Mbit SPI Flash.

4.3

The SHB103 Series supports four 240-pin DDR3 DIMM

sockets for a maximum memory of 16GB DDR3 SDRAMs.

The memory module can come in sizes of 1GB, 2GB and

4GB.

™

Core

processors, which make your

XP and Linux

Hardware Description

CHAPTER 4

2 Quad /
