  • Page 1 User’s Manual Manuel d’utilisation Bedienungsanleitung Manual de usuario Manuale d'istruzioni Gebruiksaanwijzing Instruções do Proprietário Bruksanvisningens Regulatory models: W60, W61 010-0757-00 DISPERINDAG No. 0287/1.824.51/09.03...
  • Page 2 This page left blank intentionally...
  • Page 3 Projector IN5122/IN5124 User's Manual Thank you for purchasing this projector. WARNING ►Before using this product, please read all manuals for this product. Be sure to read Safety Instructions first. After reading them, store them in a safe place for future reference.

  • Page 4: Table Of Contents

    Contents   Introduction . . . . . . . . . . . . . . . 3 SETUP menu . . . . . . . . . . . . . . 38 Features .

  • Page 5: Introduction

    Introduction Introduction Features The projector provides you with the following features: ü This projector has a variety of I/O ports that should cover all business applications. The HDMI port supports various types of image sources which have digital interfaces enabling you to display clearer images on the screen. ü...

  • Page 6: Part Names

    Introduction Part names Projector (1) Lamp cover ( 82) The lamp unit is inside. (2) Speakers (x2) (13, 41) (3) Filter cover (86) The air filter and intake vent are inside. (4) Elevator feet (x2) (20) (5) Elevator buttons (x2) (20) (6) Remote sensor (15) (7) Lens (86) (8) Lens cover...
  • Page 7 Introduction Part names (continued) Control panel and Lens adjusters (1) Lens adjuster door (2) FOCUS ring (21) (3) ZOOM ring (21) (4) HORIZONTAL adjuster (21) (5) VERTICAL adjuster ( 21) (6) LOCK (horizontal lens position lock) (21) (7) STANDBY/ON button (17) (8) SOURCE button (17) (9) MENU button (26) (10) SECURITY indicator (69)
  • Page 8 Introduction Part names (continued) Remote control (1) STANDBY/ON button (17) (2) HELP button (3) MENU button (26) (4) UP/▲ button (26) (5) PREVIOUS PAGE/◄ button (26) (6) SELECT button (26) (7) NEXT PAGE/► button (26) (8) DOWN/ ▼ button (26) (9) VOLUME + button (18) (10) CUSTOM button (51) (11) SOURCE button (18)

  • Page 9: Setting Up

    Setting up Setting up Install the projector according to the environment and manner the projector will be used in. For special installation applications such as a ceiling mount application, specific mounting accessories (Specifications in the Quick Start Guide) and service may be required. Before installing the projector, consult with your dealer about your installation application.
  • Page 10 Setting up Arrangement (continued) WARNING ►Do not install the projector near thermally conductive or flammable items. These types of items can become heated by the projector and result in a fire and burns. • Do not place the projector on a metal stand. ►Do not place the projector in a place where it may get wet.

  • Page 11: Connecting With Your Devices

    Setting up Connecting with your devices Before connecting the projector to a device, consult the device’s manual to confirm that the device is suitable for connecting with this projector and prepare needed accessories, such as a cable in accordance with the signal of the device. Consult your dealer if any needed accessories did not come with the product or if the needed accessory is damaged.
  • Page 12 Setting up Connecting with your devices (continued) Computer NOTE • Before connecting the projector to a computer, consult the computer’s manual and check the compatibility of the signal level, the synchronization methods and the display resolution output to the projector. - Some signals may require an adapter to plug into this projector.
  • Page 13 Setting up Connecting with your devices (continued) Computer Access point storage device CAUTION ► Before connecting the projector to a network system be sure to obtain the network administrator’s approval. ►Do not connect the LAN port to any network that might have excessive volt- age.
  • Page 14 Setting up Connecting with your devices (continued) Digital VCR/DVD/Blu-ray Disc player video device NOTE • The HDMI port of this model is compatible with HDCP (High-band- width Digital Content Protection) and therefore capable of displaying a video signal from HDCP compatible DVD players and the like. - The HDMI supports the following video signals: 480i@60,480p@60,576i@50,576p@50,720p@50/60,1080i@50/60,1080p@50/60 - This projector can be connected with other equipment which have HDMI con-...
  • Page 15 Setting up Connecting with your devices (continued) Monitor Speakers (with an amplifier) Microphone Wired system remote control (optional) NOTE • If loud feedback noise comes from the speakers, move the micro- phone away from the speaker. Microphone feature • You can connect a dynamic microphone to the MIC port with a 3.5 mm mini-plug. In that case, the built-in speaker outputs the sound from the microphone, even when the sound from the projector is output.

  • Page 16: Connecting To A Power Supply

    Setting up Connecting to a power supply Plug the power cord into the projector's AC IN (AC inlet) port. Firmly plug the power cord’s plug into the outlet. A few seconds after connecting the power supply, the POWER indicator will light AC IN steady orange.

  • Page 17: Remote Control

    Remote control Remote control Installing the batteries Please insert the batteries into the remote control before using it. If the remote control starts to malfunction, try replacing the batteries. If you will not be using the remote control for a long period, remove the batteries and store them in a safe place. Holding the hook part of the battery cover, remove it.

  • Page 18: Using As A Simple Pc Mouse & Keyboard

    Remote control Using as a simple PC mouse & keyboard The accessory remote control works as a simple mouse and keyboard of the computer, when the projector’s USB TYPE B port and the computer’s type A USB port are connected and MOUSE is selected for the USB TYPE B item in the OPTION menu (50).

  • Page 19: Power On And Off

    Power on and off Power on and off Turning on the power Make sure that the power cord is firmly STANDBY/ON button connected correctly to the projector and the outlet. POWER indicator Make sure that the POWER indicator is STANDBY/ON SOURCE MENU SECURITY...

  • Page 20: Operating

    Operating Operating VOLUME +/- button Adjusting the volume Use the VOLUME +/VOLUME - buttons to adjust the volume. A dialog will appear on the screen to help you adjust the volume. If you do not do anything, the dialog will automatically disappear after a few seconds.

  • Page 21: Selecting An Aspect Ratio

    Each time you press the button, the projector switches the aspect ratio mode as per below. IN5122: AUTO ó 16:10 ó 16:9 ó 4:3 IN5124: AUTO ó NATIVE ó 16:10 ó 16:9 ó 4:3 Note: For a LAN, USB TYPE A or USB TYPE B port input, or...

  • Page 22: Adjusting The Projector's Elevator

    Operating Adjusting the projector’s elevator When the location where the projector is being placed is slightly uneven to the left or right, use the elevator feet to help level the projector horizontally. Using the feet, you can also tilt the projector to project to a suitable angle to the screen, elevating the front side of the projector up to 12 degrees.

  • Page 23: Adjusting The Lens

    Operating Adjusting the lens Use the ZOOM ring to adjust the screen FOCUS ring size. ZOOM ring Use the FOCUS ring to focus the image. LOCK (Horizontal adjuster lock) Turn the VERTICAL adjuster completely HORIZONTAL counter clockwise. Then turn it clockwise adjuster and adjust the vertical lens position upward.

  • Page 24: Using The Automatic Adjustment Feature

    Operating Using the automatic adjustment feature AUTO IMAGE button Press the AUTO IMAGE button on the remote control. Pressing this button performs the following.  For a computer signal The vertical position, the horizontal position and the horizontal phase will be automatically adjusted. Make sure that the application window is set to its maximum size prior to attempting to use this feature.

  • Page 25: Correcting The Distortion

    Operating Correcting the distortion To correct the distortion of the projected screen, you can select one of three op- tions: AUTO KEYSTONE: performs automatic vertical keystone correction. (38) MANUAL KEYSTONE: allows you to adjust the vertical and horizontal keystone. CORNER CORRECTION: allows you to adjust each of the screen corners and sides to correct the distortion.
  • Page 26 Operating CORNER CORRECTION Press the MENU button to bring up the BASIC MENU. When CORNER CORRECTION is highlighted, pressing the ► or SELECT button displays the CORNER CORRECTION dialog. Select one of the corners or sides to be adjusted with the ▲/▼/◄/► buttons and press the SELECT button.

  • Page 27: Temporarily Blanking The Screen

    Operating Temporarily blanking the screen BLANK button Press the BLANK button on the remote control. The BLANK screen will display instead of the input signal image. Please refer to BLANK in the SCREEN menu (43). To exit the BLANK screen and return to the input signal screen, press the BLANK button again.

  • Page 28: Using The Menu Features

    Operating Using the menu features This projector has the following menus: BASIC MENU, PICTURE, IMAGE, INPUT, SETUP, AUDIO, SCREEN, OPTION, NETWORK, and SECURITY menus. BASIC MENU consists of commonly used features, and the other menus are organized by purpose and brought together in the ADVANCED MENU. Each of these menus can be controlled using the same methods.
  • Page 29 Operating Using the menu features (continued) To close the MENU, press the MENU button again or select EXIT and press the ◄ cursor button or SELECT button. Even if you do not do anything, the dialog will automatically disappear after about 30 seconds. ●...

  • Page 30: Basic Menu

    BASIC MENU BASIC MENU From the BASIC MENU, items shown in the table below can be performed. Highlight an item using the ▲/▼ cursor buttons and then make adjustments based on the table below. Item Description Using the ◄/► buttons switches the mode for aspect ratio. ASPECT RATIO See the ASPECT RATIO item in IMAGE menu (33).
  • Page 31 BASIC MENU Item Description Using the ◄/► buttons turns the Low Power mode on and off. LOW POWER See LOW POWER in the SETUP menu (39). Using the ◄/► buttons switches the ceiling mode. CEILING See CEILING in the SETUP menu (39). Using the ◄/►...

  • Page 32: Picture Menu

    PICTURE menu Picture menu From the Picture menu, the following items can be performed as shown in the table below. Highlight an item using the ▲/▼ cursor buttons, and press the ► cursor button or SELECT button to execute the item. Then make adjustments based on the table below.
  • Page 33 PICTURE menu Item Description Using the ▲/▼ buttons switches the color temperature mode.    1 HIGH 1 CUSTOM 2 MID 2 CUSTOM 6 CUSTOM 3 LOW 6 Hi-BRIGHT-3 3 CUSTOM    5 CUSTOM 5 Hi-BRIGHT-2 4 CUSTOM 4 Hi-BRIGHT-1 To adjust CUSTOM Highlighting a CUSTOM mode and then...
  • Page 34 PICTURE menu Item Description Using the ◄/► buttons adjusts the sharpness. Weak ó Strong SHARPNESS • There may be some noise and/or the screen may flicker for a moment when an adjustment is made. This is not a malfunction. Using the ▲/▼ cursor buttons changes the active iris control mode. PRESENTATION ó...

  • Page 35: Image Menu

    Item Description Using the ▲/▼ buttons switches the mode for aspect ratio. IN5122: AUTO ó 16:10 ó 16:9 ó 4:3 IN5124: AUTO ó NATIVE ó 16:10 ó 16:9 ó 4:3 ASPECT RATIO Note: For a LAN, USB TYPE A or USB TYPE B port input, or if...
  • Page 36 IMAGE menu Item Description Using the ◄/► buttons adjusts the vertical position. Down ó Up • Over-adjusting the vertical position may cause noise to appear on the screen. If this occurs, please reset the vertical position to its default setting. VERTICAL •...

  • Page 37: Uto Image

    IMAGE menu Item Description Using the ◄/► buttons adjusts the horizontal phase to eliminate flicker. Right ó Left PHASE • This feature is only available for computer and component signals. It is not available for LAN, USB TYPE A, USB TYPE B or HDMI™ port signals..

  • Page 38: Input Menu

    INPUT menu INPUT menu From the INPUT menu, the items in the table below can be performed. Highlight an item using the ▲/▼ cursor buttons, and press the ► cursor or SELECT button to select the item. Then make adjustments per the following table. Item Description Using the ▲/▼...

  • Page 39: Computer In

    INPUT menu Item Description The video standard for the S-video port and VIDEO port can be selected. (1) Use the ▲/▼ buttons to highlight the input port. (2) Using the ◄/► buttons switches the video standard mode. VIDEO AUTO ó NTSC ó PAL ó SECAM STANDARD N-PAL ó...

  • Page 40: Setup Menu

    SETUP menu SETUP menu From the SETUP menu, items shown in the table below can be performed. Highlight an item using the ▲/▼ cursor buttons, and press the ► cursor button or SELECT button to select the item. Then make adjustments according to the table below.
  • Page 41 SETUP menu Item Description Using the ◄/► buttons corrects the vertical keystone distortion. Shrink the right side of the image ó Shrink the left side of the image. • The adjustable range of this feature will vary based on the input. For some inputs, this feature may not work well.
  • Page 42 SETUP menu Item Description Using ▲/▼ buttons switches the power saving mode setting between ENABLE and DISABLE. ENABLE ó DISABLE When ENABLE is selected, the power consumption in the power saving mode is lowered with some functional restrictions as per below: •...

  • Page 43: Audio Menu

    AUDIO menu AUDIO menu From the AUDIO menu, items shown in the table below can be performed. Highlight an item using the ▲/▼ cursor buttons, and press the ► cursor or the SELECT button to select the item. Then make adjustments per the following table.
  • Page 44 AUDIO menu Item Description Using the ▲/▼ buttons switches the HDMI NOISE CANCEL mode. HDMI NOISE Select the best mode for your HDMI audio device. CANCEL ENABLE ó DISABLE Using the ▲/▼ buttons switches the input level to match that of the microphone connected to the MIC port.

  • Page 45: Screen Menu

    BLANK SNAPSHOT : A customized image saved through the CAPTURE NEW feature (44). FACTORY LOGO : The standard "InFocus" logo screen. BLUE, WHITE, BLACK : Plain screens in each color. • To avoid screen burn-in, the SNAPSHOT or FACTORY LOGO screen will change to a plain black screen after several minutes.
  • Page 46 SCREEN menu Item Description This feature allows you to capture an image for use as a SNAPSHOT image which then can be used as both a BLANK screen and a START UP LOGO screen. Display the image you want to capture before executing the following procedure. 1.
  • Page 47 SCREEN menu Item Description Using the ▲/▼ buttons turns the CAPTURE LOCK feature on and off. ON ó OFF When the ON is selected, the item SNAPSHOT is locked. Use this CAPTURE LOCK feature to protect the current SNAPSHOT. • This feature cannot be selected if the SNAPSHOT PASSWORD is set to ON in SECURITY menu (65).
  • Page 48 SCREEN menu Item Description Each input port's name can be customized on this projector. (1) Use the ▲/▼ buttons on the SCREEN menu to highlight SOURCE NAME and press the ► or SELECT button. The SOURCE NAME menu will display. (2) Use the ▲/▼...
  • Page 49 SCREEN menu Item Description (6) The current name will display on the first line. Use the ▲/▼/◄/► buttons and the SELECT button to select and enter characters. To erase 1 character at a time, press the ◄ and SOURCE button simultaneously.
  • Page 50 SCREEN menu Item Description Closed captioning displays a transcript or dialog of the audio portion of a video, files, presentation or other relevant sounds. An NTSC format video or a 480i@60 format component video source which supports closed captioning is required to use this feature.

  • Page 51: Option Menu

    OPTION menu OPTION menu From the OPTION menu, items shown in the table below can be performed. Highlight an item using the ▲/▼ cursor buttons, and press the ► cursor or the SELECT button to select the item (except for RESET LAMP HOURS and RESET FILTER HOURS).
  • Page 52 OPTION menu Item Description Automatically turns the projector off after no signals are detected for 30 minutes. AUTO POWER Please refer to Turning off the power (17). Using the ▲/▼ buttons selects the USB TYPE B port feature. To use this feature, you need to connect the USB TYPE B projector port and the type A USB port of a computer.
  • Page 53 OPTION menu Item Description This item assigns one of the following features to CUSTOM on the remote control (6). (1) Use the ▲/▼ buttons on the CUSTOM KEY menu to select a CUSTOM KEY and press the ► or SELECT button to display the CUSTOM KEY setup dialog.
  • Page 54 OPTION menu Item Description Selecting this item displays the SERVICE menu. Highlight an item using the ▲/▼ buttons, and press the ► button or the SELECT button on the remote control to select the item. FAN SPEED HIGH Using the ▲/▼ buttons switches the rotation speed of the cooling fans.
  • Page 55 OPTION menu Item Description FILTER MESSAGE Use the ▲/▼ button to set the timer which notifies users when it is time to replace the filter unit: 100h ó 200h ó 500h ó 1000h ó 2000h ó 5000h ó OFF After choosing the desired hours parameter (excluding OFF), the message “REMINDER *** HRS PASSED ..”...
  • Page 56 OPTION menu Item Description COMMUNICATION TYPE Select the communication type for transmission via the CONTROL port. NETWORK BRIDGE ó OFF NETWORK BRIDGE: Select this type, if you will be controlling an external device from a computer via this projector. The CONTROL port does not accept RS-232C commands (Network Bridge in the Network Guide) OFF: Select this mode to receive RS-232C...
  • Page 57 OPTION menu Item Description RESPONSE LIMIT TIME Select the desired wait time for response data from the external device communicating via the NETWORK BRIDGE and the HALF-DUPLEX mode through the CONTROL port. OFF ó 1s ó 2s ó 3s OFF: Select OFF when it is not necessary to check for responses from the external device that the projector is sending data to.
  • Page 58 OPTION menu Item Description SOURCE INFO A read-only display of current source settings. • This item cannot be selected when there is no signal or sync out. • When MY TEXT DISPLAY is set to ON, MY TEXT is displayed together with the input information in the SOURCE_INFO box (76).

  • Page 59: Network Menu

    NETWORK menu NETWORK menu Remember that incorrect network settings on this projector may create problems on your network. Be sure to consult with your network administrator before connecting to an existing access point on your network. Select “NETWORK” from the main menu to access the following features.
  • Page 60 NETWORK menu Item Description Use the ▲/▼/◄/► buttons to enter the IP ADDRESS. This feature can only be used when DHCP is set to OFF. • The IP ADDRESS is the number that identifies IP ADDRESS this projector on the network. You cannot have two devices with the same IP ADDRESS on the same network.
  • Page 61 NETWORK menu Item Description (1) Use the ▲/▼ buttons on the NETWORK menu to select the PROJECTOR NAME and press the ► button. The PROJECTOR NAME dialog will display. (2) The current PROJECTOR NAME will display on the first 3 lines. A particular projector name is pre-assigned by default.
  • Page 62 NETWORK menu Item Description Selecting this item displays the MY IMAGE menu. To store images in the projector, the application software PJImg/Projector Image Tool is required (this can be downloaded from our website). Use the ▲/▼ buttons to select a saved MY IMAGE image ( My Im- age Feature in the Network Guide) and the ►...
  • Page 63 NETWORK menu Item Description Selecting this item displays the PRESENTATION menu. Use the ▲/▼ buttons to select one of the following items, then press ► or SELECT button to use the feature. If you set a computer to Presenter mode and its image is projected by the projector, all other computers are blocked from presenting.
  • Page 64 NETWORK menu Item Description • To change from Multi PC mode to Single PC mode, select one of the computers in the dialog using the ▲/▼/◄/► buttons and press the SELECT button. Press the ► button to choose OK, and then press SELECT again.
  • Page 65 NETWORK menu Item Description Selecting this displays the NETWORK_INFO dialog to confirm network settings. NETWORK INFO • For the PASSCODE details, refer to Selecting the network connection method in the Network Guide. • Only the first 16 characters of the projector name are displayed. •...

  • Page 66: Security Menu

    Enter the SECURITY menu 1. Press the ► button. The SELECT PASSWORD box will display. 2. Use the ▲/▼/◄/► buttons to enter the correct password. The factory default password is as follows. IN5122: 4102 IN5124: 2502 (below) This password can be changed .
  • Page 67 SECURITY menu Item Description The SNAPSHOT PASSWORD feature can be used to prevent access to the CAPTURE NEW feature and prevent the currently saved SNAPSHOT image from being overwritten. 1 Turning on the SNAPSHOT PASSWORD 1-1 Use the ▲/▼ buttons on the SECURITY menu to select SNAPSHOT PASSWORD and press the ►...
  • Page 68 SECURITY menu Item Description PIN LOCK is a feature which prevents the projector from being used unless a saved password is input. 1 Turning on the PIN LOCK 1-1 Use the ▲/▼ buttons on the SECURITY menu to select PIN LOCK and press the ► button or the SELECT button to display the PIN LOCK on and off menu.
  • Page 69 SECURITY menu Item Description If the projector's vertical angle or CEILING/REAR settings change and this feature is set ON, the projector will not display an input signal. In addition, if the projector is powered off and moved, the TRANSITION DETECTOR ON alarm will display.

  • Page 70: Y Text Password

    SECURITY menu Item Description The MY TEXT PASSWORD feature can prevent the MY TEXT from being overwritten. When the password is set for MY TEXT; • The MY TEXT DISPLAY menu will be unavailable, and can prevent DISPLAY settings from being changed. •...
  • Page 71 SECURITY menu Item Description (1) Use the ▲/▼ buttons on the SECURITY menu to select the MY TEXT DISPLAY and press the ► or SELECT button to display the MY TEXT DISPLAY on and off menu. (2) Use the ▲/▼ buttons on the MY TEXT DISPLAY on and off menu to select on or off.

  • Page 72: Presentation Tools

    • GIF (.gif) NOTE • Files with resolutions larger than the following are not supported. IN5122: 1024X768 IN5124: 1280 x 800 (* Some computers may not support 1280 x 800.) • Files with a resolution smaller than 36x36 are not supported.

  • Page 73: Thumbnail Mode

    Presentation tools PC-LESS Presentation (continued) Thumbnail mode The Thumbnail mode displays the images stored in a USB storage device on the Thumbnail screen. A maximum of 20 images will be displayed on the screen. If you wish, you can jump into Full Screen or Slideshow mode, after you select an image in the Thumbnail mode.
  • Page 74 Presentation tools PC-LESS Presentation (continued) Operating by buttons or keys You can control the images in the Thumbnail screen with the remote control, projector keypad or using web browser software. The following features are supported when the Thumbnail mode is displayed. Button operation The projector Web Remote in web...
  • Page 75 Presentation tools PC-LESS Presentation (continued) Operating the menu on the Thumbnail screen You can also control the images using the menu on the Thumbnail screen. Item Features Moves to an upper folder. SORT Allows you to sort files and folders as per the following. Press the ►...
  • Page 76 Presentation tools PC-LESS Presentation (continued) NOTE • These options are not available when the projector OSD is displayed. • The Thumbnail mode shows 20 images maximum per page. • You cannot change input ports using the SOURCE button when the Thumbnail screen, Slideshow, or Full Screen is displayed.

  • Page 77: Full Screen Mode

    Presentation tools PC-LESS Presentation (continued) Full Screen Mode The Full Screen mode shows a full display image. To display in Full Screen mode, select an image in the Thumbnail screen. Then press the SELECT button on the remote control or the SOURCE button on the keypad, or click [SELECT] on the Web Remote Control.

  • Page 78: Slideshow Mode

    Presentation tools PC-LESS Presentation (continued) Slideshow mode The Slideshow mode displays images in full screen and switches the images at intervals set in INTERVAL on the Thumbnail screen menu (71). You can start this feature from the Slideshow menu. To display the Slideshow menu, select the SLIDESHOW button in the Thumbnail mode and press the SELECT button on the remote control or projector's SOURCE button.
  • Page 79 Presentation tools PC-LESS Presentation (continued) You can play the Slideshow with your desired configuration. Configure the Slideshow items in the Thumbnail. 1) RETURN : Returns to the thumbnail mode. 2) PLAY : Play the Slideshow. 3) START : Set the beginning number of the Slideshow.
  • Page 80 Presentation tools PC-LESS Presentation (continued) Playlist The Playlist is a DOS format text file, which determines the image file order in the Thumbnail or Slideshow view. The playlist file name is “playlist.txt” and it can be edited on a computer. It is created in the same folder which contains your selected image files when PC- LESS Presentation is started or Slideshow is configured.

  • Page 81: Usb Display

    • The image transmission from the computer is suspended when the password- protected screen saver is running. To resume the transmission, exit the screen saver. • Check our website (www.infocus.com/support) for the latest version of the software and its manual. Follow the upgrade instructions on the website.
  • Page 82 Presentation tools USB Display (continued) Right-Click menu The menu shown in the right will display when you right-click the application icon in the Windows notification area. Display : The Floating menu is displayed, and the icon disappears from the Windows notification area. Quit : The application is closed, and the icon disappears from the Windows notification area.

  • Page 83: Options Window

    If you remove the check mark from the [Keep PC resolution] box, your computer's screen resolution will change per below, and the display speed may be faster. IN5122: 1024X768 (XGA) IN5124: 1280 x 800 (WXGA) If your computer does not support the display resolutions specified above, the closest smaller supported resolution will be selected.

  • Page 84: Maintenance

    Maintenance Replacing the lamp Be sure to use the InFocus lamp module designed for this projector. You can order new lamps from www.infocus.com (in select areas), your retailer or your dealer. Only genuine InFocus lamps are tested for use in this projector. Use of non InFocus lamps may cause electrical shock and fire, and may void the projector warranty.

  • Page 85: Lamp Warning

    Maintenance Replacing the lamp (continued) Lamp warning HIGH TEMPERATURE HIGH PRESSURE HIGH VOLTAGE WARNING ►The projector uses a high-pressure mercury glass lamp. The lamp can break with a loud bang, or burn out, if jolted or scratched, handled when hot, or worn over time.

  • Page 86: Cleaning And Replacing The Air Filter

    Maintenance Cleaning and replacing the air filter Please check and clean the air filter periodically. When the indicators or a message prompts you to clean the air filter, comply with it as soon as possible. This projector’s air filter consists of a filter cover and a filter unit with two types of filter.
  • Page 87 Maintenance Cleaning and replacing the air filter (continued) Put the filter cover back into place. Turn the projector on and reset the filter hours using the RESET FILTER HOURS item in the BASIC MENU. (1) Press the MENU button to display the menu. (2) Highlight RESET FILTER HOURS using the ▲/▼...

  • Page 88: Other Care

    Maintenance Other care Inside the projector In order to ensure the safe use of your projector, please have it cleaned and inspected by your dealer every year. Caring for the lens If the lens is flawed, soiled or fogged, it could cause display quality deterioration. Please take good care of the lens and handle cautiously.

  • Page 89: Ertical Position Troubleshooting

    Troubleshooting Troubleshooting If the projector is operating abnormally, stop using the projector immediately. WARNING ►Never use the projector if abnormal conditions occur such as Troubleshooting smoke, strange odors, excessive sounds, damaged casing, elements or cables, penetration by liquids or foreign matter, etc. In this situation, immediately disconnect the power plug from the power outlet.
  • Page 90 Troubleshooting Related messages (continued) Message Description The internal temperature is rising. Please turn the power off, and allow the projector to cool down at least 20 minutes. After having confirmed the following items, please turn the power ON again. • Is anything blocking the air vents? •...

  • Page 91: Regarding The Indicator Lamps

    Troubleshooting Regarding the indicator lamps When the LAMP, TEMP and POWER indicator operate differently than usual, follow the instructions below in the following table. For the SECURITY indicator, see SECURITY INDICATOR in the SECURITY menu. POWER LAMP TEMP Description indicator indicator indicator Solid...

  • Page 92: Resetting All Settings

    Troubleshooting Regarding the indicator lamps (continued) POWER LAMP TEMP Description indicator indicator indicator There is a possibility that the projector has overheated. Please turn the power off, and allow the projector to cool down at least 20 minutes. After the projector has sufficiently cooled down, please check Blinking the following items, and then turn the power on again.

  • Page 93: Situations That May Be Easy To Be Mistaken For Projector Defects

    Troubleshooting Situations that can be easily mistaken as a projector defect The following situations can be misinterpreted as a projector defect. Review the following table before arranging for a repair. Reference Phenomenon Situations not caused by a projector defect page The electrical power cord is unplugged.
  • Page 94 Troubleshooting Situations that can be easily mistaken as a projector defect (continued) Reference Phenomenon Situations not caused by a projector defect page The signal cables are not connected correctly. 9 ~ 13 Correctly connect the audio cables. MUTE is on. Restore sound by pressing MUTE or the VOLUME +/- button on the remote control.
  • Page 95 Troubleshooting Situations that can be easily mistaken a projector defect (continued) Reference Phenomenon Situations not caused by a projector defect page Color settings are not correctly adjusted. Perform image adjustments by changing the COLOR Colors look 31, 36 TEMPERATURE, COLOR, TINT and/or COLOR SPACE settings, faded- out using the menu features.
  • Page 96 Troubleshooting Situations that can be easily mistaken for a projector defect (continued) Reference Phenomenon Situations not caused by a projector defect page The computer The computer cannot start up in the current hardware connected to configuration. the USB TYPE Disconnect the USB cable from the computer, then B projector port reconnect it after starting up the computer.

  • Page 97: Specifications

    Specifications Specifications Please see the Specifications in the Quick Start Guide. End User License Agreement for the Projector Software • Software in this projector consists of multiple independent software modules and there are existing copyrights or/and third party copyrights for each of these software modules.
