InFocus IN5124 User Manual

Rs232 command and control guide
Hide thumbs Also See for IN5124:

Advertisement

Quick Links

Download this manual See also: Network Manual, Manual
RS232 Command and Control Guide
Regulatory models: W60, W61
010-0763-00
DISPERINDAG No. 0287/1.824.51/09.03

Advertisement

loading
Need help?

Need help?

Do you have a question about the IN5124 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for InFocus IN5124

Summary of Contents for InFocus IN5124

  • Page 1 RS232 Command and Control Guide Regulatory models: W60, W61 010-0763-00 DISPERINDAG No. 0287/1.824.51/09.03...
  • Page 2 This page left blank intentionally...
  • Page 3 Projector IN5122/IN5124 RS232 Command and Control Guide The signals listed on the following pages are used for initial setup, however the signal timings of some computer models may be different. In such a case, adjust V POSITION and H POSITION in the IMAGE menu.
  • Page 4 Initial set signals IN5122 Computer Mode Table Resolution Freq Standard DotCLK fV (Hz) H Total H Res H Sync H Back V Total V Res V Sync V Back (MHz) (KHz) (Pixels) (Pixels) (Pixels) Porch (Lines) (Lines) (Lines) Porch (Pixels) (Lines) 720x400 VESA-DMT...
  • Page 5 Initial set signals IN5124 Computer Mode Table Resolution Freq Standard DotCLK fV (Hz) H Res H Sync H Back V Total V Res V Sync V Back (MHz) (KHz) (Pixels) (Pixels) Porch (Lines) (Lines) (Lines) Porch H Total (Pixels) (Lines)

  • Page 6: Monitor Out

    Connection to the ports Connection to the ports NOTICE ►Use the cables with straight plugs, not L-shaped ones, as the input ports of the projector are recessed. ►Only the signal that is input from the COMPUTER IN1 or IN2 can be output from the MONITOR OUT port.
  • Page 7 Connection to the ports (continued) COMPUTER IN2 (G/Y, B/Cb/Pb, R/Cr/Pr, H, V) • BNC jack x 5 • Video : Analog 0.7Vp-p, 75Ω terminator • H/V, sync, : TTL level (positive/negative) • Composite sync, : TTL level COMPONENT (Y, Cb/Pb, Cr/Pr) RCA jack x3 •...
  • Page 8 Connection to the ports (continued) HDMI 10 12 14 • Type :Digital audio/video connector • Audio signal : Linear PCM (Sampling rate; 32/44.1/48 kHz) 13 15 Signal Signal Signal T.M.D.S. Data2 + T.M.D.S. Data0 Shield 15 SCL T.M.D.S. Data2 Shield T.M.D.S.
  • Page 9 Connection to the ports (continued) USB TYPE A USB TYPE B USB A type jack USB B type jack Signal Signal - Data - Data + Data + Data Ground Ground CONTROL D-sub 9pin plug • About the details of RS-232 communication, 6 7 8 please refer to the section "RS-232 Communication".
  • Page 10 Connection to the ports (continued) To input SCART RGB signal; SCART SCART connector (jack) SCART cable (plug) RCA plugs To input SCART RGB signal to the projector, use a SCART to RCA cable. Connect the plugs refer to above example. For more reference, please consult your dealer.
  • Page 11 RS-232 Communication RS-232 Communication When the projector connects to the computer by RS-232 communication, the projector can be controlled with RS-232 commands from the computer. For details of RS-232 commands, refer to RS-232 Communication / Network command table (&16). Connection Turn off the projector and the computer.

  • Page 12: Command Control Via The Network

    Command Control via the Network Command Control via the Network When the projector is connected to the network, the projector can be controlled with RS-232 commands from the computer with a web browser. For RS-232 command information, refer to the RS-232 Communication / Network command table (&16).

  • Page 13: Communication Port

    Command Control via the Network (continued) Communication Port The following port is assigned for command control. TCP #23 Configure the following items from a web browser when command control is used. Port Settings Click the [Enable] check box to open [Network Port open Control Port1 (Port: 23)] to use TCP #23.
  • Page 14 Command Control via the Network (continued) RS-232 Commands IMPORTANT: When formatting commands sent from a control system or computer, enclose commands in parentheses “(“ and “)”. When entering custom commands into Scheduled Tasks in the projector’s web interface, enclose commands in less than/ greater than symbols “<”...
  • Page 15 Command Control via the Network (continued) A write request example: (AAA####) where (starts the command AAA denotes the command #### denotes the value to be written (leading zeros not necessary) ) ends the command Some commands have ranges, while others are absolute. If a number greater than the maximum range is received, it is automatically set to the maximum number for that function.
  • Page 16 Network Bridge Communication Network Bridge Communication This projector is equipped with NETWORK BRIDGE function. When the projector connects to the computer by LAN communicaton, an external device that is connected with this projector by RS-232 communication can be controlled from the computer as a network terminal. For details, see the 6.

  • Page 17: Communication Settings

    Network Bridge Communication Communication settings For communication setting, use the OPTION - SERVICE - COMMUNICATION menu. (&OPTION menu - SERVICE - COMMUNICATION in the User's Manual) Item Condition BAUD RATE 4800bps / 9600bps / 19200bps / 38400bps Data length 8 bit (fixed) PARITY NONE/ODD/EVEN Start bit...
  • Page 18 RS-232 Communication / Network command table RS-232 Communication / Network command table Function Command RW Default Step BASIC MENU Aspect Ratio 0: Auto 1: Native (IN5124 only) 2: 4:3 3: 16:9 6: 16:10 Auto Keystone Execute 1: Execute Horizontal Keystone Vertical Keystone Corner Correction Enable...
  • Page 19 RS-232 Communication / Network command table (continued) Function Command Default Step Presets 5 (Computer in 1) 1: User 5 (Computer in 2) 5: Presentation 5 (LAN) 7: Video 5 (USB Type A) 10: Bright 5 (USB Type B) 11: Whiteboard 15 (HDMI) 12: Blackboard 15 (Component)
  • Page 20 RS-232 Communication / Network command table (continued) Function Command Default Step Gamma 32: 1 Default 32 (Computer in 16: 1 Custom 33: 2 Default 32 (Computer in 17: 2 Custom 34: 3 Default 32 (LAN) 18: 3 Custom 32 (USB Type A) 35: 4 Default 32 (USB Type B) 19: 4 Custom...
  • Page 21 RS-232 Communication / Network command table (continued) Function Command Default Step Gamma Custom-4 Point 7 Gamma Custom-4 Point 8 Gamma Custom-5 Point 1 Gamma Custom-5 Point 2 Gamma Custom-5 Point 3 Gamma Custom-5 Point 4 Gamma Custom-5 Point 5 Gamma Custom-5 Point 6 Gamma Custom-5 Point 7 Gamma Custom-5 Point 8 Gamma Custom-6 Point 1...
  • Page 22 RS-232 Communication / Network command table (continued) Function Command Default Step Color Temperature - 6 Blue Gain Color Temperature - 1 Red Offset Color Temperature - 2 Red Offset Color Temperature - 3 Red Offset Color Temperature - 4 Red Offset Color Temperature - 5 Red Offset Color Temperature - 6 Red Offset Color Temperature - 1 Green Offset GF1...
  • Page 23 RS-232 Communication / Network command table (continued) Function Command Default Step ADVANCED MENU: IMAGE Aspect Ratio 0: Auto 1: Native (IN5124 Only) 2: 4:3 3: 16:9 6: 16:10 Overscan 0: Off 1: Zoom 2: Crop if def<128: Vertical Position def +128...
  • Page 24 Vertical Keystone Corner Correction Enable 0: Disable 1: Enable Corner Correction Top Left corner 511 (IN5122) 639 (IN5124) Corner Correction Top Left corner Corner Correction Top Right corner 511 (IN5122) 639 (IN5124) Corner Correction Top Right corner Corner Correction Bottom Left...
  • Page 25 Reset 0: n/a 1: enable Side Correction Left Gain Side Correction Right Gain 768 (IN5122) 384(IN5124) Side Correction V Position 800 (IN5124) 400(IN5124) Side Correction Top Gain Side Correction Bottom Gain 512(IN5124) 1024 (IN5122) Side Correction H Position 640(IN5124) 1280 (IN5124)
  • Page 26 RS-232 Communication / Network command table (continued) Function Command Default Step Monitor Out for Source 5 (HDMI) 1: Computer in 1 2: Computer in 2 255: Off Monitor Out for Source 6 (Component) 1: Computer in 1 2: Computer in 2 255: Off Monitor Out for Source 7 (S-Video)
  • Page 27 RS-232 Communication / Network command table (continued) Function Command Default Step Audio for Source 0 (Computer in 1) 0: Audio 1 1: Audio 2 2: Audio 3 5: Mute Audio for Source 1 (Computer in 2) 0: Audio 1 1: Audio 2 2: Audio 3 5: Mute Audio for Source 2 (LAN)
  • Page 28 RS-232 Communication / Network command table (continued) Function Command Default Step HDMI Noise Cancel 0: Disable 1: Enable MIC Level 0: Low 1: High MIC Volume ADVANCED MENU: SCREEN Menu Positon H 0 (left) Menu Positon V 10 (top) Blank Screen 0: Blue 3: Black 4: white...
  • Page 29 RS-232 Communication / Network command table (continued) RS-232 Communication / Network command table (continued) Function Command Default Step Auto Power 0: Disable 1: Enable USB Type B 0: Mouse 1: USB Display Custom Key (Effect) 0: Blank 1: Mute 2: Aspect Ratio 3: Source 4: Auto Image 5: Freeze...
  • Page 30 RS-232 Communication / Network command table (continued) RS-232 Communication / Network command table (continued) Function Command Default Step Source 4 0: Computer in 1 1: Computer in 2 2: LAN 3: USB Type A 4: USB Type B 5: HDMI 6: Component 7: S-Video 8: Video...
  • Page 31 RS-232 Communication / Network command table (continued) Function Command Default Step My Image Display 0: Off 1: Image-1 2: Image-2 3: Image-3 4: Image-4 My Image Delete Image-1 1: delete My Image Delete Image-2 1: delete My Image Delete Image-3 1: delete My Image Delete Image-4 1: delete...
  • Page 32 RS-232 Communication / Network command table (continued) Function Command Default Step Freeze 0: Off 1: On INFOCUS UNIQUE About (Source Info) 0: n/a 1: enable Lamp Lit 0: not lit 1: lit Number of Lamp Resets 32766 Lamp Total On Time (All Bulbs)

  • Page 33: Pjlink Command

    PJLink command PJLink command Commands Control Description Parameter or Response 0 = Standby POWR Power Control 1 = Power On 0 = Standby POWR ? Power Status inquiry 1 = Power On 2 = Cool Down 11 = COMPUTER IN 1 12 = COMPUTER IN 2 21 = COMPONENT 22 = S-VIDEO...
  • Page 34 Manufucturer's Name INF1 ? INFOCUS inquiry INF2 ? Model Name inquiry Your model name, "IN5122", or "IN5124" Responds with the factory information and so INFO ? Other Information inquiry CLSS ? Class Information inquiry 1 NOTE • The password used in PJLink is the same as the password set in the Web Browser Comtrol.

This manual is also suitable for:

In5122
