IPC912 Series User's Manual
1.2

System Specifications

1.2.1

Main CPU Board

CPU
Socket P Intel
System Chipset
®
Intel GM45+ICH9M chipset
BIOS
AMI BIOS, with Smart View and Customer CMOS Backup.
System Memory
Two 204-pin DDR3 800/1066 MHz SODIMM sockets, with
maximum up to 8GB
Features
Fanless Operation
Compact & Front IO design
Supports Two expansion slots
DC to DC power supply support 10V to 30V
1.2.2

I/O System

Standard I/O Interface -- Front
ATX power on/off switch
One 2-pin connector output for remote power on/off switch
10VDC to 30VDC with phoenix power plug or External 150W
AC Adapter
Six USB 2.0 ports
HDD access/Power LEDs
Three RS232(COM 2/3/4)
One RS232/422/485(COM 1)
One VGA connector
Two 10/100 LAN ports
Introduction
® TM
Core 2 Duo/Celeron
®
M processors
3
