  • Page 1 Series Embedded System User’s Manual...

  • Page 2: Disclaimers

    Axiomtek does not make any commitment to update any information in this manual. Axiomtek reserves the right to change or revise this document and/or product at any time without notice. No part of this document may be reproduced, stored in a retrieval system, or transmitted in any forms or by any means, electronic, mechanical, photocopying, recording, among others, without prior written permissions of Axiomtek Co., Ltd.

  • Page 3: Safety Precautions

    Safety Precautions Before getting started, please read the following important safety precautions. The eBOX700-891-FL does not come with an operating system which must be loaded first before installation of any software into the computer. Be sure to ground yourself to prevent static charge when installing any internal components.

  • Page 4: Classifications

    Classifications Degree of production against electric shock: not classified Degree of protection against ingress of water: IP40 Equipment not suitable for use in the presence of a flammable anesthetic mixture with air, oxygen or nitrous oxide. Mode of operation: Continuous...

  • Page 5: General Cleaning Tips

    General Cleaning Tips Please keep the following precautions in mind while understanding the details fully before and during any cleaning of the computer and any components within. A piece of dry cloth is ideal to clean the device. Be cautious of any tiny removable components when using a vacuum cleaner to absorb dirt on the floor.

  • Page 6: Scrap Computer Recycling

    Scrap Computer Recycling Please inform the nearest Axiomtek distributor as soon as possible for suitable solutions in case computers require maintenance or repair; or for recycling in case computers are out of order. Trademarks Acknowledgments Axiomtek is a trademark of Axiomtek Co., Ltd.

  • Page 7: Table Of Contents

    Table of Contents Disclaimers ......................ii Safety Precautions ....................iii Classifications ....................... iv General Cleaning Tips ................... v Scrap Computer Recycling ................... vi SECTION 1 INTRODUCTION .................. 1 General Descriptions ................. 1 System Specifications ............... 2 1.2.1 CPU ........................2 1.2.2 I/O System ......................
  • Page 8 3.3.12 AT/ATX Switch (SW1) ..................31 3.3.13 SATA Connector (SATA 1 & 2) ..............32 3.3.14 SATA Power Connector (CN8) ..............32 3.3.15 SIM Card Slots (SCN1) .................. 32 3.3.16 Full-Size PCI Express Mini Card Slot (SCN2 & SCN3) ....... 33 3.3.17 PCI-Express x4 slot (PCIE1) .................

  • Page 9: Section 1 Introduction

    Series user’s Manual SECTION 1 INTRODUCTION This section contains general information and detailed specifications of the eBOX700-891-FL.Section 1 consist of the following sub-sections:  General Descriptions  System Specifications  Dimensions  I/O Outlets  Packing List  Model List 1.1 General Descriptions...

  • Page 10: System Specifications

    Series user’s Manual Features ® ® Core™ i7/i5/i3 & Celeron  LGA1151 socket 6th/7/th generation Intel ® processor with Intel H110  Supports Jumbo Frame (9.5k), W oL, PXE Remote Boot, Teaming  W ide range of DC power input supported from 9 to 36VDC ...

  • Page 11: I/O System

    Series user’s Manual 1.2.2 I/O System  Display  2 x HDMI (1 x HDMI 2.0 Resolution:4K/2K@60Hz & 1 x HDMI 1.4b Resolution : 4K/2K@30Hz)  1 x DisplayPort (Resolution:4K/2K@60Hz)  Ethernet  4 x 10/100/1000 Ethernet ports (3 x i210IT & 1 x i219LM) ...

  • Page 12: System Specifications

    Series user’s Manual 1.2.3 System Specifications  Watchdog Timer  1~255 seconds or minutes; up to 255 levels.  Power Supply  9~36VDC input  Operation Temperature  -40℃ ~+50℃ (-40 ºF ~ 122ºF), with W .T. SSD & Memory) ...

  • Page 13: Dimensions

    Series user’s Manual 1.3 Dimensions The following diagrams show dimensions and outlines of the eBOX700-891-FL. 1.3.1 System Dimensions Introduction...

  • Page 14: Wall-Mount Bracket Dimensions

    Series user’s Manual 1.3.2 Wall-mount Bracket Dimensions Introduction...

  • Page 15: Din-Rail Bracket Dimensions

    Series user’s Manual 1.3.3 Din-rail Bracket Dimensions Introduction...

  • Page 16: I/O Outlets

    Series user’s Manual 1.4 I/O Outlets The following figures show I/O outlets on the eBOX700-891-FL. Front View Rear View Reset switch DisplayPort Phoenix connector(9~36VDC) ATX/AT Quick switch HDMI 1.4 4 x GbE LANs ATX Power switch 2 x USB 2.0 HDMI 2.0...

  • Page 17: Packing List

    Fanless Embedded System with LGA1151 Socket 6th/7th Gen Intel® Core™ i7/i5/i3& Celeron® Processor, Intel® H110, 2 eBOX670-891-FL-DC- Flexible IO HDMI/DisplayPort, 4 GbE LANs, 6 USB,1 PCIe x4 Expansion and 9 ~ 36 VDC Please contact Axiomtek’s distributors immediately in case any abovementioned items are missing. Introduction...
  • Page 18 Series user’s Manual This page is intentionally left blank. Introduction...

  • Page 19: Section 2 Hardware Installation

    Series user’s Manual SECTION 2 HARDWARE INSTALLATION The eBOX700-891-FL is convenient for various hardware configurations, such as CPU, DRAM, HDD (Hard Disk Drive), SSD (Solid State Drive), PCIe x4 expansion slot and PCI Express Mini card modules. Section 2 contains guidelines for hardware installation.
  • Page 20 Series user’s Manual Step 4 CPU installation steps:  Lift processor package from shipping media by grasping the substrate edges.  Scan the processor package gold pads for any presence of foreign material.  Locate connection 1 indicator on the processor which aligns with connection 1 indicator chamfer on the socket, and notice processor keying features that line up with posts along socket walls.
  • Page 21 Series user’s Manual Step 5 Align pins of the CPU with pin holes of the socket. Be careful of the CPU’s orientation that user’s need to align the arrow mark on the CPU with the arrow key on the socket.

  • Page 22: Installation Of 2.5" Sata Device

    Series user’s Manual 2.2 Installation of 2.5" SATA Device Step 1 Turn off the system. Step 2 Turn the system upside down to locate screws at the bottom and then loosen all screws. Step 3 Open the bottom cover.
  • Page 23 Series user’s Manual Step 5 Before assemble the SSD/HDD, please prepare HDD bracket/HDD/ screws, and then assemble the SSD / HDD with the HDD mounting screws. Make sure the PCB side of the SSD/HDD will be facing the bottom cover.

  • Page 24: Installation Of So-Dimm

    Series user’s Manual 2.3 Installation of SO-DIMM Step 1 Turn off the system. Step 2 Four screws on the top heatsink are used to fasten the heatsink to the chassis. Step 3 Located the dual SO-DIMM sockets on main board.

  • Page 25: Installation Of Pcie Card

    Series user’s Manual 2.4 Installation of PCIe card Step 1 Turn off the system Step 2 Turn the system upside down to locate screws at the bottom, and then loosen all screws. Step 3 Identify the location of the PCIe slot as below red marked.
  • Page 26 Series user’s Manual Step 5 Insert the PCIe card and fasten the screw of PCIe card adjustable bracket. Step 6 Fasten the small bracket screw and put the bottom cover back onto the chassis. Hardware Installation...

  • Page 27: Installation Of Flexible I/O Modules

    Series user’s Manual 2.5 Installation of Flexible I/O Modules The eBOX670-891 provides an optional window for custom er add flexible I/O modules, according to different modules , please re follow the below Instructions: -AX92902 LAN Module (RJ45 connector*1) -AX92904 DIO Module (DB44 connector*1)
  • Page 28 Series user’s Manual Step 4 Loosen the two screws of flexible IO door and push the hole which is not punched through. Step 5 Insert the CAN Bus mini PCIe card (One mini card with one DB 9 connector) Step 6 Assemble CAN Bus connector with bracket.
  • Page 29 Series user’s Manual Step 7 Fasten the CAN Bus connector with bracket onto the chassis, and then connect the CAN Bus cable to the mini PCIe card. Step 8 Put the bottom cover and fasten two screws back onto the system.

  • Page 30: Installation Of Usb Dongle Kit

    Series user’s Manual 2.6 Installation of USB Dongle kit The eBOX670-891 provides an adjustable USB dongle bracket for customer use: Step 1 Turn off the system. Step 2 Turn the system upside down to locate screws at the bottom and then loosen all screws.

  • Page 31: Section 3 Jumper & Connector Settings

    Series user’s Manual SECTION 3 JUMPER & CONNECTOR SETTINGS Proper jumper settings configure the eBOX700-891-FL to meet various application needs. Hereby all jumpers settings along with their default settings are listed for devices onboard. 3.1 Locations of Jumpers & Connectors SBC87891 Top View Jumper &...
  • Page 32 Series user’s Manual SBC87891 Bottom View It is strongly recommended that any unmentioned jumper settings should not be modified without instructions by Axiomtek FAEs. Note Any modifications without instructions might cause system failure. Jumper & Connector Settings...

  • Page 33: Summary Of Jumper Settings

    Series user’s Manual 3.2 Summary of Jumper Settings Proper jumper settings configure the eBOX700-891-FL to meet various application purposes. A table of all jumpers and their default settings is listed below. Jumpers Descriptions Settings Restore BIOS Optimal Defaults Short 1-2 Default: Normal Operation How to setup Jumpers.

  • Page 34: Connectors

    Series user’s Manual 3.3 Connectors Please refer to pin assignments below: External Connectors Sections DC-in Phoenix Power Connector 3.3.1 HDMI Connector 3.3.2 DisplayPort Connector 3.3.3 Serial Port Connector 3.3.4 USB 3.0 Connector 3.3.5 Ethernet Connector 3.3.6 USB 2.0 Connector 3.3.7...

  • Page 35: Dc-In Phoenix Power Connector (Cn17)

    Series user’s Manual 3.3.1 DC-in Phoenix Power Connector (CN17) The system supports 9~36V Phoenix DC-in connector for system power input. Pins Signals 3.3.2 HDMI Connector (CN11/CN3) The HDMI (High-Definition Multimedia Interface) is a compact digital interface which is capable of transmitting high-definition video and high-resolution audio over a single cable.

  • Page 36: Displayport Connector (Cn4)

    Series user’s Manual 3.3.3 DisplayPort Connector (CN4) Pins Signals Pins Signals DPB_LANE0 DPB_LANE3# DPB_LANE0# Detect Pin DPB_LANE1 DPB_AUX DPB_LANE1# DPB_LANE2 DPB_AUX# DPB_HPDE DPB_LANE2# DPB_LANE3 +3.3V 3.3.4 Serial Port Connector (CN18/CN19) The system has two serial ports. COM1~COM2 are RS-232/422/485 ports. Please refer to Chapter 4 for the detail of BIOS setting.

  • Page 37: Usb 3.0 Connector (Cn14/Cn15)

    Series user’s Manual 3.3.5 USB 3.0 Connector (CN14/CN15) The Universal Serial Bus connectors are compliant with USB 3.0 (5 GB/s), and ideally for installing USB peripherals such as scanner, camera and USB devices, etc. Pins Signal USB Port 0...

  • Page 38: Usb 2.0 Connector (Cn5)

    Series user’s Manual 3.3.7 USB 2.0 Connector (CN5) The Universal Serial Bus connectors are compliant with USB 2.0 (480Mbps), and ideally for installing USB peripherals such as keyboard, mouse, scanner, etc. Pins Signal USB Port USB VCC (+5V level)

  • Page 39: Atx Power On/Off (Sw3)

    Series user’s Manual 3.3.9 ATX Power On/OFF (SW3) The ATX power button is on the I/O side. It can allow users to control eBOX700-891-FL power on/off. Functions Descriptions Turn on/off system Keep system status 3.3.10 Reset Button (SW2) The Reset button can allow users to reset eBOX700-891-FL.

  • Page 40: Sata Connector (Sata 1 & 2)

    Series user’s Manual 3.3.13 SATA Connector (SATA 1 & 2) These Serial Advanced Technology Attachment (Serial ATA or SATA) connectors are for high-speed SATA interfaces. They are computer bus interfaces for connecting to devices such as hard disk drives. This board has two SATA 3.0 ports with 6Gb/s performance.

  • Page 41: Full-Size Pci Express Mini Card Slot (Scn2 & Scn3)

    Series user’s Manual 3.3.16 Full-Size PCI Express Mini Card Slot (SCN2 & SCN3) The eBOX700-891-FL supports dual full-size PCI-Express Mini Card slots.SCN2 is applying to either PCI-Express or USB 2.0 signal, and complies with PCI-Express Mini Card Spec. V1.2.
  • Page 42 Series user’s Manual SCN3 Pins Signals Signals W AKE# +3.3VSB No use No use +1.5V CLKREQ# No use No use REFCLK- No use REFCLK+ No use No use No use No use W _DISABLE# PERST# PE_RXN3/mSATA +3.3VSB SATA_RXP PE_RXP3/mSATA SATA_RXN +1.5V...

  • Page 43: Pci-Express X4 Slot (Pcie1)

    Series user’s Manual 3.3.17 PCI-Express x4 slot (PCIE1) The eBOX700-891-FL supports one PCI-express x4 slot. Signal Signal +12V_PS +12V_PS +12V_PS +12V_PS +12V_PS SMB_CLK_RESUME SMB_DATA_RESUME +3.3V_PS +3.3V_PS +3.3V_SB +3.3V_PS PCH_W AKE_N PW RGD CLKOUT_PCIE_P5 PCIE1_SLOT1_TX_DP_C CLKOUT_PCIE_N5 PCIE1_SLOT1_TX_DN_C PCIE1_SLOT1_RX_DP_C PCIEX4_SLOT1_PRSNT2_N PCIE1_SLOT1_RX_DN_C...
  • Page 44 Series user’s Manual This page is intentionally left blank. Jumper & Connector Settings...

  • Page 45: Section 4 Bios Setup Utility

    Series user’s Manual SECTION 4 BIOS SETUP UTILITY This section provides users with detailed descriptions in terms of how to set up basic system configurations through the BIOS setup utility. 4.1 Starting To enter the setup screens, follow the steps below: Turn on the computer and press the <Del>...

  • Page 46: Main Menu

    Series user’s Manual 4.3 Main Menu The Main Menu screen is the first screen users see when entering the setup utility. Users can always return to the Main setup screen by selecting the Main tab. System Time/Date can be set up as described below.

  • Page 47: Advanced Menu

    Series user’s Manual 4.4 Advanced Menu The Advanced menu also allows users to set configuration of the CPU and other system devices. Users can select any items in the left frame of the screen to go to sub menus: ►...
  • Page 48 Series user’s Manual ACPI Settings Use this screen to select options for the ACPI configuration, and change the value of the selected option. A description of the selected item appears on the right side of the screen. ACPI Sleep State When the sleep button is pressed, the system will be in the ACPI sleep state.
  • Page 49 Series user’s Manual CPU Configurations This screen shows the CPU version and its detailed information. Hyper-Threading Enable or disable Hyper-threading Technology, which allows a single physical processor to multitask as multiple logical processors. When disabled, only one thread per enabled core is enabled.
  • Page 50 Series user’s Manual SATA Configurations In this Configuration menu, you can see the currently installed hardware in the SATA ports. During system boot up, the BIOS automatically detects the presence of SATA devices. BIOS Setup Utility...
  • Page 51 Series user’s Manual PCH-FW Configuration This screen shows ME Firmware information. BIOS Setup Utility...
  • Page 52 Series user’s Manual NCT6102D Super IO Configurations Use this screen to select options for the NCT6102D Super IO Configurations, and change the value of the selected option. A description of the selected item appears on the right side of the screen.
  • Page 53 Series user’s Manual Serial Port 1~2 (COM1~2) Configurations Use these items to set parameters related to serial ports 1~2. BIOS Setup Utility...
  • Page 54 Series user’s Manual Serial Port 2 BIOS Setup Utility...
  • Page 55 Series user’s Manual Hardware Monitor This screen monitors hardware health status. This screen displays the temperature of system and CPU, system voltages (VCORE, +3.3V, +12V and +5V). BIOS Setup Utility...
  • Page 56 Series user’s Manual USB Configurations USB Devices Display all detected USB devices. BIOS Setup Utility...
  • Page 57 Series user’s Manual Utility Configurations This screen is for BIOS flash utility. BIOS Flash Utility BIOS flash utility configuration. BIOS Setup Utility...

  • Page 58: Chipset Menu

    Series user’s Manual 4.5 Chipset Menu The Chipset menu allows users to change the advanced chipset settings. Users can select any of the items in the left frame of the screen to go to the sub menus: ► System Agent (SA) Configurations ►...
  • Page 59 Series user’s Manual System Agent (SA) Configurations Graphics Configuration Use this item to configure internal graphics controller. Memory Configuration Use this item to refer to the information related to system memory. BIOS Setup Utility...
  • Page 60 Series user’s Manual Graphic Configurations BIOS Setup Utility...
  • Page 61 Series user’s Manual Memory Configurations This screen shows the system memory information. BIOS Setup Utility...
  • Page 62 Series user’s Manual PCH-IO Configurations This screen allows users to set PCH parameters. BIOS Setup Utility...
  • Page 63 Series user’s Manual Security Menu Administrator Password This item indicates whether an administrator password has been set (installed or uninstalled). User Password This item indicates whether a user password has been set (installed or uninstalled). BIOS Setup Utility...

  • Page 64: Boot Menu

    Series user’s Manual 4.6 Boot Menu The Boot menu allows users to change boot options of the system. Setup Prompt Timeout Use this item to set up number of seconds to wait for setup activation key where 65535(0xFFFF) means indefinite waiting.

  • Page 65: Save & Exit Menu

    Series user’s Manual 4.7 Save & Exit Menu The Save & Exit menu allows users to load system configurations with optimal or fail-safe default values. Save Changes and Exit When users have completed the system configuration changes, select this option to leave Setup and return to Main Menu.
  • Page 66 Series user’s Manual Save Changes When completed the system configuration changes, select this option to save changes. Select Save Changes from the Save & Exit menu and press <Enter>. Select Yes to save changes. Discard Changes Select this option to quit Setup without making any permanent changes to the system configurations.

  • Page 67: Appendix Awatchdog Timer

    Series user’s Manual APPENDIX A WATCHDOG TIMER About Watchdog Timer Software stability is major issue in most applications. Some embedded systems are not watched by human for 24 hours. It is usually too slow to wait for someone to reboot when computer hangs.

  • Page 68: Sample Program

    Series user’s Manual Sample Program The following example enables configurations using debug tool. Enable WDT  Enable configuration: O 2E 87; Un-lock super I/O O 2E 87  Select logic device: O 2E 07 O 2F 08  WDT device enable:...

  • Page 69: Appendix Bprogrammable Led

    Series user’s Manual APPENDIX B PROGRAMMABLE LED About Programmable LED eBOX700-891-FL supports four programmable LED which allows user to program the LED status. It can do as special indicator or alarm. Please refer to Driver CD for sample code and demo tool.
  • Page 70 Series user’s Manual This page is intentionally left blank Programmable LED...
