IPC912 Series User's Manual
1.5
Jumper Settings
The IPC912 has a number of jumpers inside the chassis that allow you
to configure your system to suit your application. The table below lists
the functions of the various jumpers.
These jumpers select the COM1 port's communication
mode to operate RS-232 or RS-422/485.
Description Function
COM1
RS-232
(Default)
RS-422
RS-485
Introduction
Jumper Setting
JP1
JP2
JP1
JP2
JP1
JP2
JP3
JP3
JP3
