CompactFlash™ Device Setting Jumper (JP8~11)
Jumper
Description Jumper Setting
CF Device
Enable
(Default)
ComplactFlash™ Voltage Selection Jumper (JP12)
This jumper is to select the voltage for CompactFlash
Description
TM
CompactFlash
Voltage Selection
CMOS Clear Jumper (JP19)
You may need to use this jumper to clear the CMOS memory if
incorrect settings in the Setup Utility.
Description
CMOS Clear
10
Description
Disable
Function
3.3V (Default)
5V
Function
Normal (Default)
Clear CMOS
Jumper Setting
TM
interface.
Jumper Setting
Jumper Setting
