IPC912 Series User's Manual
Expansion Slot
HAB100: One PCIex1 & 1 PCIex4 or 2 PCIex1
HAB103: One PCI & One PCIex4
HAB102: One PCIex4 & One PCI-X
NOTE The maximum power rating for expansion slots at
45℃can not be exceeded the following values
+5V+5Vsb+3.3V<34W
+5V+3.3V+12V<48W
1.2.3

System Specification

Drive Capacity
Supports One 2.5" HDD driver bay; one onboard
CompactFlash
Power Input
10VDC to 30VDC with phoenix power plug
External 150W AC Adapter
–
Power Input : 100VAC to 240VAC
–
Power Output : 19VDC@7.89A
Operation Temperature
Ambient with air flow: 0℃ ~ 45℃
Storage Temperature
-20℃ ~ 80℃
Humidity
10% ~ 90% (Non-condensing)
Dimensions
142mm (5.6") (W) x 248 mm (9.7") (D) x 185mm (7.3") (H)
NOTE All specifications and images are subject to change
without notice.
4
™
