Compaq TL891 - DLT Tape Library User Manual page 91

10
9
8
Figure 3-16. Base Module SCSI Connectors, Terminators and Cables
(Fast/Wide Interface, Independent Bus Connection Shown)
1 SCSI Terminator
2 DLT0
3 DLT1
4 Expansion Unit Interface
5 Power Connector
Compaq Confidential – Need to Know Required
Writer: Everett Godaire Project: TL891 MiniLibrary System User's Guide Comments:
Part Number: ER-TL891-UA.A01 File Name: d-ch3 Installation Last Saved On: 3/2/99 2:30 PM
1 1
2
3
7
4
5
6
6 Power Cable
7 Fan
8 SCSI Cables
9 SCSI Interface
10
Library Connectors (not
used in Slave Mode)
Installation 3-33
SHR-1246
