Base Module Indicators
There are four LED indicators on the Base Module control panel, labeled
(green), Cleaner (yellow), Drive Fault (red), and Loader Fault
Ready Use
(red), that serve as follows:
Ready (green) - illuminates when the Base Module is ready to accept
commands, either from the control panel or from the host computer via
the Expansion Unit. The
Menu Mode.
(yellow) - indicates that either or both drives require
Use Cleaner
cleaning. A cleaning operation should be performed as described in
Chapter 5, Regular Maintenance. When the
on, you can find out which drive needs cleaning by selecting Cleaning
Needed on the Drive Status submenu.
Drive or Loader Fault
on the LCD display. The Fault Screen is described later in this chapter.
A list of fault symptom codes (FSC) and error recovery procedures
(ERP) appears in Chapter 5, Regular Maintenance.
Figure 2-3. MiniLibrary Base Module Control Panel
Buttons - All Modules
There are four buttons on the control panel, labeled
The buttons do not directly control specific functions or options. Instead, you
use the buttons to navigate from the Default Screen through a multi-level
menu structure, then select the desired option from the appropriate menu using
Compaq Confidential – Need to Know Required
Writer: Everett Godaire Project: TL891 MiniLibrary System User's Guide Comments:
Part Number: ER-TL891-UA.A01 File Name: c-ch2 Operation Last Saved On: 3/1/99 2:14 PM
indicator goes out when you enter the
Ready
Use Cleaner
(red) - illuminates when a Fault Screen appears
Escape
Operation 2-5
LED comes
SHR-1248
, , , and
Enter
