Interface (Ports & Jacks)

Ports and Jacks

Item
Card Reader

DC-In Jack

e-SATA/USB 2.0 Port

/e-SATA
A

HDMI-Out Port

A - 2 Interface (Ports & Jacks)
The card reader allows you to use the following digital storage cards:
SD (Secure Digital) / Mini SD / SDHC / SDXC
Push the card into the slot and it will appear as a removable device.
Plug the supplied AC/DC adapter into this jack to power your computer.
This is a combined e-SATA (external Serial Advanced Technology Attachment)/ USB 2.0
compatible port.
Plug external Serial ATA hard drives into this e-SATA (external Serial Advanced Technology At-
tachment) port. *See
"USB 3.0 Port" on page A - 5
The HDMI-Out (High-Definition Multimedia Interface) port is an audio/video connector
interface for transmitting uncompressed digital streams. This allows you to connect an external
monitor, TV or Flat Panel Display etc. as a display device (see
Display (NVIDIA)" on page C -
audio and video signals (see
Description
MMC (MultiMedia Card) / RSMMC
MS (Memory Stick) / MS Pro / MS Duo
for further USB port information.
6) by means of a HDMI cable. Note that HDMI carries both
"HDMI Audio Configuration" on page C -
"Configuring an External
17).
