Interface (Ports & Jacks)
Ports and Jacks
Item
Card Reader
DC-In Jack
HDMI-Out Port
A
Headphone-Out Jack
Line-In Jack
A - 2 Interface (Ports & Jacks)
The card reader allows you to use the following digital storage cards:
SD (Secure Digital) / Mini SD / SDHC / SDXC (up to UHS-II)
Push the card into the slot and it will appear as a removable device.
Plug the supplied AC/DC adapter into this jack to power your computer.
The HDMI-Out (High-Definition Multimedia Interface) port is an audio/video connector
interface for transmitting uncompressed digital streams. This allows you to connect an external
monitor, TV or Flat Panel Display etc. as a display device (see
Display (NVIDIA)" on page C -
audio and video signals.
Headphones or speakers may be connected through this jack. Note: Set your system's volume
to a reduced level before connecting to this jack.
The Line-In jack allows you to play audio sources through the computer's speakers. Note that
audio input through Line-in will default to the mute setting. To set up your audio sources to play
through the Line-in jack go to the Sound
checked.
Description
MMC (MultiMedia Card) / RSMMC
17) by means of a HDMI cable. Note that HDMI carries both
control panel and make sure the Mute box is not
"Configuring an External
