Bios; Storage; Audio; Keyboard & Pointing Device - EUROCOM Notebook V12.3.10 User Manual

BIOS

One 64Mb SPI Flash ROM
AMI BIOS

Storage

Up to three (Factory Option)
Changeable 2.5" 9.5 mm (h) SATA
(Serial) Hard Disk Drives supporting
RAID level 0/1/5
One 12.7 mm Super Multi/Blu-Ray
Combo/Blu-Ray Writer SATA Optical
Device Drive (Factory Option)

Audio

High Definition Audio
S/PDIF Digital Output
Built-In Microphone
5 Built-In Speakers
One built-in 3W Sub woofer
THX® TruStudio Pro Surround Sound
External 7.1CH Audio output supported
by headphone, microphone, S/PDIF &
Line-In Jack
Keyboard & Pointing Device
Full Size Winkey Illuminated Keyboard
with Numeric Keypad
Built-In TouchPad (with Multi Gesture
Functionality)
Six Touch Sensor Instant Keys (Volume
Up, Volume Down, Mute, WLAN,
Bluetooth & PC Camera)
W/A/S/D Gaming Keys

Card Reader

Embedded Multi-In-1 Card Reader
- MMC / RSMMC
- SD / Mini SD / SDHC / SDXC
- MS / MS Pro / MS Duo
Note: Some of these cards require PC
adapters that are usually supplied with
the cards.
Specifications

Slots

One ExpressCard™ (34/54) Slot
One Mini Card Slot for WLAN & Bluetooth
Combo Half Mini-Card Module with PCIe
& USB Interface

Interface

Three USB 3.0 Ports (Including one AC/
DC Powered USB/ eSATA Combo Port)
Two USB 2.0 Ports
One eSATA Port (SATA Interface, C/DC
Powered USB 3.0 Combo)
One Mini-IEEE1394b Port
One DisplayPort (Version is Video
Controller Dependant)
One DVI-I Out Port (Single Link)
One HDMI (High-Definition Multimedia
Interface) 1.4a Out Port (with HDCP
Support)
One Headphone/Speaker-Out Jack
One Microphone-In Jack
One S/PDIF Out Jack
One Line-In Jack
One RJ-45 LAN Jack
One DC-In Jack
Specifications D - 3
D
