11. Replace the fan unit above the RAM module slot and replace screws
reconnect the cable
29
12. Insert the heatsink
30
tab under the CPU heat sink when inserting it).
.
28
25
26
27
(make sure not to trap or catch the plastic VGA heat sink
30
-
25
29
31
Upgrading the System Memory (RAM) 6 - 21
Upgrading The Computer
28

Figure 6 - 23

Fan Unit Screws &
Cable
31
Figure 6 - 24
Heatsink Insertion
6
