Upgrading The Computer
6
Figure 6 - 16
Reconnect the
Keyboard LED
Cable
6 - 16 Upgrading the System Memory (RAM)
15. Replace the screws and shielding plate.
16. Replace the keyboard and make sure you reconnect the keyboard cable.
17. When reconnecting the keyboard LED cable
gold colored contact is facing upwards to fit inside the connector. Make sure you
tuck the cable into the recess in the shield plate to avoid trapping it between the
keyboard and the shielding plate.
, twist the cable slightly so that the
23
23
