LED Indicators

The two sets of LED indicators (LED Status Indicators and LED Power Indicators) display helpful informa-
tion about the current status of the computer.
Icon Color
Blinking
Blue
Number Lock is Activated
Blue
Blue
Scroll Lock is Activated
Blue
*Note: The powered USB 3.0/e-SATA port (see
+ Power Button key combination (press for around 1 to 2 seconds to toggle). When the powered USB port is on it will
supply power (for charging devices only, not for operating devices) when the system is off but still powered by the AC/
DC adapter plugged into a working outlet, or powered by the battery with a capacity level above 20% (this may not work
with certain devices - see page
Description
Hard Disk Activity
Caps Lock is Activated
Table 1 - 1 - LED Status Indicators
Figure 1 - 7 on page 1 -
8 - 13).
Icon Color
Orange
Green
Blinking Green
Blinking Orange*
Orange
Blinking Orange
Green
17) may be toggled on /off by means of the Fn
System Map: LCD Panel Open & Top View 1 - 7
Quick Start Guide
Description
DC Power is Plugged In
The Computer is On
The Computer is In Sleep Mode
The Powered USB Port is On*
The Battery is Charging
The Battery has Reached Critically
Low Power Status
The Battery is Fully Charged
1
