Euphonix Version 4 Supplement to the R-1 Operation Manual

7.7

Transfer Station Drive Bay Configuration

To enable all the drive bays for the Transfer Station, you must select them in the Con-

figuration dialog:

1. Right-click on the Media/Titles button and select Configure.

The Configure menu has two sections: Enable PCI Decks and Transfer Station

SCSI Controller.

Under Enable PCI Decks, you can turn on and off drive bays connected to the

Transfer Station to mimic any size R-1.

3. For your settings to take place, restart the application.

4. Under the Transfer Station SCSI Controller section you can tell the application

what SCSI controller to use. This section is only used during set up and the set-

tings should not be changed. The correct SCSI controller code name should be

ADPU160M.

There are two ADPU160M ports in a Transfer Station, so if you need to select the cor-

rect one, use the first one found by the system when changing the SCSI controller.

When testing that you have set this up correctly, do not use drives with important data.

If you have chosen the wrong SCSI controller you will lose all the data on the drives.

Transfer Station
