Euphonix Version 4 Supplement to the R-1 Operation Manual
Chapter 3: Display Features
This section introduces version 4's new display features:
•
Waveform display
•
Zoom controls
•
Reel Trim and cursor-based Jog and Shuttle
•
Clip-edge Locating
•
Bars, Beats, and Ticks display mode
3.1
Waveform Display
The R-1 shows waveforms for all Clips in the track sheet unless you choose otherwise.
All waveforms are drawn bipolar. The 3-D tubular Clips in previous versions have been
abandoned in favor of simpler waveform displays. Waveforms allow you to more easily
see gaps in the content, fully silent edit points, clipping or near clipping, downbeats, and
similar material on separate tracks. Depending on your level of experience with using
waveforms, you may even recognize certain instruments.
Figure 3-1 Dragging the clip edge handle of a waveform
13
