Configuration And Patches; Configuration And Patches Tab - Euphonix R-1 Operation Manual

Euphonix Version 4 Supplement to the R-1 Operation Manual
8.3

Configuration and Patches

Begin by selecting the Configurations and Patches tab and make a new configuration
in the Configuration window. Several configuration types are available from in the New
menu. Activate your configuration by double-clicking it or selecting it and pressing the
Open button. It is active when it has a red check mark next to it. Then use the Patches
window to create and name a new patch.
• New: creates a new blank patch.
• Recall: activates the selected patch.
• Store: stores the patch settings.
Select the Edit Current Configuration tab. The following buttons are available:
• Add Device
• Rename Device
• Remove Device
• Declare Connection
Figure 8-5 Configuration and Patches tab
69
Miscellaneous Features
