Euphonix Version 4 Supplement to the R-1 Operation Manual

Chapter 2: Wiring Instructions

2.1 Firewire
1. Connect a firewire cable from the Pilot PC to the Studio Hub.
2. Connect a firewire cable from the Studio Hub to the Audio Deck 1.
3. Connect a firewire cable from the Audio Deck 1 to the Audio Deck 2.
4. Connect a firewire cable from the Audio Deck 2 to the Audio Deck 3.
5. Connect a firewire cable from the Audio Deck 3 to the Audio Deck 4.
NOTE: Do not connect the firewire cables in any other way than as described.
2.2 AES Clock
1. Connect an AES cable from the AES Out on the Studio Hub to the AES In on
a converter.
2. Connect an AES cable from the AES Through on the converter to the AES In
on the Audio Deck.
3. Repeat until all Converters and Decks have AES clock connected. If you prefer
Word Clock, use the same procedure to the Word Clock connectors.
2.3 MADI
To use the MADI routes built into the Studio Hub you must connect the MADI devices
in the following order:
1. AM 713 #1 MADI Output to Studio Hub MADI port Input 1
2. MA 703 #1 MADI Input to Studio Hub MADI port Output 1
3. AM 713 #2 MADI Output to Studio Hub MADI port Input 2
4. MA 703 #2 MADI Input to Studio Hub MADI port Output 2
5. AM 713 #3 MADI Output to Studio Hub MADI port Input 3
6. MA 703 #3 MADI Input to Studio Hub MADI port Output 3
7. AM 713 #4 MADI Output to Studio Hub MADI port Input 4
8. MA 703 #4 MADI Input to Studio Hub MADI port Output 4
9. Audio Deck #1 MADI Output to Studio Hub Input 7
11
