2.4

Cybex Extender

Connect a fan-out cable from the cybex transmitter to different ports on the computer.

1. PS2 mouse cable connects to PS2 mouse port on computer (may require im-

pedance box).

2. PS2 keyboard cable connects to PS2 keyboard port on computer (may require

impedance box).

3. 9-pin mouse cable connects to remote port on computer.

4. Monitor cable connects to monitor port on computer.

5. CAT 5 network cable connects Cybex transmitter and receiver.

Connect a fan-out cable from the cybex receiver to different devices on the Remote.

1. PS2 mouse cable connects to PS2 mouse on Remote.

2. PS2 keyboard cable connects to PS2 keyboard on Remote.

3. 9-pin mouse cable connects to RS232-to-RS422 converter which connects to

Remote.

4. Monitor cable connects to monitor on Remote.
