Euphonix Version 4 Supplement to the R-1 Operation Manual
6.2

Selection Features

6.2.1

Select Clip with Select Clip Button

Select a clip underneath the Now Line on a selected track and edit it using the remote's
Clip menu or the mouse.
1. Select the track on which to select a clip using the Select buttons on the remote.
2. Position the Now Line above the clip to select.
3. Press the Select Clip button.
The clip is highlighted and active for editing.
6.2.2

Slip Clip Using Trim Buttons and Jog Wheel on Remote

A new Clip menu has been added to the remote activated by a new Clip button to the
right of the Track button.
Select a clip and the press the Clip button. The first level of the menu has the following
options: Slip Position, Slip Head Trim, Slip Tail Trim, Slip Audio Sync, Adjust
Fade In, Adjust Fade Out, Cut, Copy, and Split. When one of these options is select-
ed, the trim buttons allow time mode dependant adjustment. The scrub wheel does a
zoom-level dependant adjustment of the parameter. The clip is adjusted as indicated un-
less it reaches a max/min limit.
NOTE: If a clip is not selected, the menu options would be Select Inc Clips and Select Adj
Clips. The former selects all clips completely included in the selection region. The lat-
ter selects all clips that are at least partially contained in the selection region.
The edits are immediate so the menu need not be closed to see the changes. Moving a
clip trims adjacent clips as required. The changes are not final until exiting the menu.
If the menu is canceled, the sheet reverts to its pre-menu state, even if edits were done
with the trackball while the menu was open. Even after closing the menu, an Undo op-
eration can revert to the previous state.
One notable change in this feature set is Slip Position, which can be used in combina-
tion with Reel Trim to easily slip audio into sync using the waveforms as your guide.
For example, when aligning a loose bass line with a kick drum. Select the bass sound,
turn on Reel Trim and reel rock so the Now Line is at the beginning edge of the bass
line's waveform attack. Select Slip Position from the Remote's Clip menu, then press
the Select button next to the Locate time window. This sets the marker for the clip you
wish to slip. Now reel rock so the now line is at the beginning of the waveform attack
of the kick drum. Press the Select button next to the Locate time window. The bass line
will slip into it's new position.
Editing and Selection Features
53
