Appendix B • Packaging For Shipment - Extron electronics Cable Cubby 200 User Manual

Packaging for Shipment, cont'd
Cut-Out Template for Extron's
Cable Cubby 800
8.360" (21.23 cm)
6.820"
+
6.320 0.0325"
(17.32 cm)
+
(16.05 0.083 cm)
SURFACE CUT-OUT
AREA =
7.860 0.0325 "( 19.96 0.083 cm) x
6.320 0.0325"(16.05 0.083 cm)
Cut surface material
out along this line.
User Access
TEMPLATE IS NOT FULL SIZE.
Figure A-8 — Cable Cubby 800 cut-out template
®
A-16 Cable Cubby Products • Packaging for Shipment
+
+
+ +
+ +
(1.3 cm)
Top Panel
Cut-Out Radius:
0.25"
(0.6 cm)
Cable Cubby
0.5"
®
Products
B
A ppendix B
Packaging for Shipment
