Packaging for Shipment, cont'd
Cut-Out Template for Extron's
Cable Cubby 200
.350" (1.90 cm)
SURFACE CUT-OUT
AREA =
0.5"
(1.3 cm)
Cut-Out Radius:
Cut surface material
0.25"
out along this line.
(0.6 cm)
Figure A-4 — Cable Cubby 200 cut-out template
®
A-12 Cable Cubby Products • Packaging for Shipment
4.394" (11.16 cm)
+
+
+
3.155 0.0325"
+
(8.01 0.083 cm)
+
x 7.185 0.0325"
+
(18.25 0.083 cm)
+
7.185 0.0325"
+
(18.25 0.083 cm)
Top Panel
6.470"
(16.4 cm)
8.00
(20.32
Cut-Out Template for Extron's
Cable Cubby 300S
5.130" (13.0 cm)
+
+
SURFACE CUT-OUT
+
AREA =
4.625 0.0325"
+
(11.75 cm) x 5.970 0.0325"
5.970"
+
(15.16 0.083 cm)
(15.2 cm)
Cut surface material
Top Panel
out along this line.
User Access
TEMPLATE IS NOT FULL SIZE.
Figure A-5 — Cable Cubby 300S cut-out template
Cable Cubby ® Products • Packaging for Shipment
0.5"
(1.3 cm)
Cut-Out Radius:
0.25"
(0.6 cm)
