im Vertrieb von
Extron Electronics, USA
Extron Electronics, Europe
1230 South Lewis Street
Beeldschermweg 6C
Anaheim, CA 92805
3821 AH Amersfoort
USA
The Netherlands
714.491.1500
+31.33.453.4040
www.extron.com
Fax 714.491.1517
Fax +31.33.453.4050
www.camboard.de
© 2006 Extron Electronics. All rights reserved.
CAMBOARD Electronics
Extron Electronics, Asia
Extron Electronics, Japan
135 Joo Seng Road, #04-01
Kyodo Building
PM Industrial Building
16 Ichibancho
Singapore 368363
Chiyoda-ku, Tokyo 102-0082 Japan
+65.6383.4400
+81.3.3511.7655
Fax +65.6383.4664
Fax +81.3.3511.7656
Tel. 07131 911201
Fax 07131 911203
User's Manual
Surface Access Products for Cables, AAPs, and Power Outlets
ce-info@camboard.de
Cable Cubby
®
200
®
Cable Cubby
300C
Cable Cubby
®
300S
®
Cable Cubby
600
Cable Cubby
®
800
68-701-01 Rev. G
10 06

Advertisement

Table of Contents
loading

Related Manuals for Extron electronics Cable Cubby 600

Summary of Contents for Extron electronics Cable Cubby 600

  • Page 1 16 Ichibancho 10 06 The Netherlands Singapore 368363 Chiyoda-ku, Tokyo 102-0082 Japan 714.491.1500 +31.33.453.4040 +65.6383.4400 +81.3.3511.7655 www.extron.com Fax 714.491.1517 Fax +31.33.453.4050 Fax +65.6383.4664 Fax +81.3.3511.7656 www.camboard.de Tel. 07131 911201 ce-info@camboard.de © 2006 Extron Electronics. All rights reserved. Fax 07131 911203...
  • Page 2 Vermeidung einer Überhitzung der empfi ndlichen Teile im use. In no event will Extron Electronics be liable for direct, indirect, or consequential Aufbewahren der Anleitungen • Die Hinweise zur elektrischen Sicherheit Inneren. Diese Öffnungen dürfen niemals von anderen Objekten blockiert werden.
  • Page 3 im Vertrieb von CAMBOARD Electronics www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...
  • Page 4 im Vertrieb von CAMBOARD Electronics www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...

  • Page 5: Table Of Contents

    im Vertrieb von CAMBOARD Electronics Table of Contents Chapter 1 • Introducton ............1-1 About the Cable Cubby Products ® ........1-2 Features ..................1-5 Chapter 2 • Installaton .............. 2-1 Installation Overview ..............2-2 Preparing the Routing Template ...........
  • Page 6 im Vertrieb von CAMBOARD Electronics Table of Contents, cont’d 68-701-01.Rev. G 10.06 All trademarks mentioned in this manual are the properties of their respective owners. www.camboard.de Tel. 07131 911201 ce-info@camboard.de Cable Cubby Products • Table of Contents ® Fax 07131 911203...

  • Page 7: Chapter 1 • IntroductOn

    im Vertrieb von CAMBOARD Electronics Cable Cubby Products ® Chapter One Introducton About.the.Cable.Cubby .Products ® Features www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...
  • Page 8 Cable Cubby 800 USA/domestic model — Eight single- space (single-height) AAPs • Cable Cubby 800 (international model) — Seven single- space (single-height) AAPs • Cable Cubby 600 USA/domestic model — Six single- space AAPs • Cable Cubby 600 (international model) — Five single- space AAPs •...
  • Page 9 im Vertrieb von CAMBOARD Electronics Figure 1-1 — Cable Cubby 300S US/domestic enclosure The AAP spaces inside the cubbies allow you to customize the enclosure to meet your unique needs, with the included split double space AAPs and Extron’s full line of optional passive AAPs.
  • Page 10 im Vertrieb von CAMBOARD Electronics Introducton, cont’d The installed Cable Cubbies fit nearly flush within a table or podium top, storing the AAPs and cables out of the way and out of sight. To access the AAPs and connectors, lift the lid (figure 1-2).

  • Page 11: Features

    im Vertrieb von CAMBOARD Electronics Features • Easy access to cables and AAPs • Durable mechanical movement • Cable Cubby 300, 600, and 800 available in a variety of surface finishes • Compact size • Flexible installation of Extron passive AAPs •...
  • Page 12 im Vertrieb von CAMBOARD Electronics Introducton, cont’d www.camboard.de Tel. 07131 911201 ce-info@camboard.de Cable Cubby Products • Introduction ® Fax 07131 911203...

  • Page 13: Chapter 2 • InstallatOn

    im Vertrieb von CAMBOARD Electronics Cable Cubby Products ® Chapter Two Installaton Installation.Overview Preparing.the.Routing.Template Preparing.the.Table Installing.the.Cables.and.AAPs Mounting.the.Cable.Cubby www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...
  • Page 14 im Vertrieb von CAMBOARD Electronics Installaton Installaton Overvew Install and set up the Cable Cubby enclosures as follows: If you plan to use a mounting template that has not been prepared, prepare the template. See Preparing the Routing Template, later in this chapter. Cut a hole in the surface where the enclosure will be installed.
  • Page 15 im Vertrieb von CAMBOARD Electronics Preparng the Routng Template Extron provides metal templates for the Cable Cubbies at no charge. See Routing Template Part Numbers, in appendix A, Reference Information, for part numbers. Extron recommends using this template as a guide to cut the hole in the table where the cubby will be installed.

  • Page 16: Preparing The Table With A Router

    im Vertrieb von CAMBOARD Electronics Installaton, cont’d Preparng the Table The preferred and recommended method for preparing the table for square Cable Cubbies and one of two preferred methods for the Cable Cubby 300C is to use the appropriate Extron routing template and a router.
  • Page 17 im Vertrieb von CAMBOARD Electronics Wear safety glasses when operating the router. Failure to comply can result in eye injury. Using a router with a 5/8" (or 16 mm) outside diameter guide bushing and a 1/2" (or 12 mm or 12.7 mm) diameter straight router bit, carefully cut the opening in the surface (figure 2-2).

  • Page 18: Preparing The Table With A Hole Saw

    im Vertrieb von CAMBOARD Electronics Installaton, cont’d Preparng the table wth a hole saw (Cable Cubby 300C only) Prepare the table with a hole saw as follows: On the tabletop or other installation surface, mark the 6" circle, then find and mark the center of the circle. Wear safety glasses when operating the drill.

  • Page 19: Installing The Cables And Aaps

    im Vertrieb von CAMBOARD Electronics Installng the Cables and AAPs Each Cable Cubby 300, 600, and 800 model ships with one or two moveable AAP shelf assemblies. The Cable Cubby 200’s AAP shelf is fixed in place. AAP shelf brackets (CC 300, 600, and 800) Each shipped AAP shelf assembly consists of a set of shelf brackets and a number of cable pass-through (split) AAPs.

  • Page 20: Installing The Power Module (Cc 300, 600, And 800)

    im Vertrieb von CAMBOARD Electronics Installaton, cont’d Installng the power module (CC 300, 600, and 800) From the underside of the Cable Cubby, gently push the power module into the desired position at the desired elevation. Secure the power module into position with four Phillips head screws. Installng the cables Three half-moon cutouts in each set of cable pass-through (split) AAPs loosely channel three cables in the cubby.

  • Page 21: Installing The Aaps

    im Vertrieb von CAMBOARD Electronics Install cables in the channels as follows: Remove a segment of a set of split AAPs by unscrewing the nuts on the underside of the bracket that fastens the plate to the shelf (CC 200) or shelf bracket (CC300, 600, or 800).

  • Page 22: Installing The Shelf Assembly (Cc 300, 600, And 800)

    im Vertrieb von CAMBOARD Electronics Installaton, cont’d Installng the shelf assembly (CC 300, 600, and 800) From the underside of the Cable Cubby, gently push the AAP shelf assembly into the desired position at the desired elevation. Ensure there is enough space above the AAP assembly for the Cable Cubby lid to close completely.

  • Page 23: Mounting The Cable Cubby

    im Vertrieb von CAMBOARD Electronics Install a second stand-off, in accordance with steps 1 and 2. Slide the stand-offs back and forth in the horizontal slots to position them so that the cables easily rise and lower but do not fall below the stand-offs. Tighten the Phillips head screws to lock the stand-offs into position.
  • Page 24 im Vertrieb von CAMBOARD Electronics Installaton, cont’d Carefully lower the Cable Cubby into the hole to test the fit. If necessary, remove the enclosure and use a file or rasp to enlarge or smooth the edges of the opening (figure 2-7). 15-pin HD Cable Cable Cubby 300C Audio Cable...
  • Page 25 im Vertrieb von CAMBOARD Electronics Cable Cubby 200 — Use the four included 6-32 x 1/2" screws to fasten the Cable Cubby 200 to the table (figure 2-8). Figure 2-8 — Cable Cubby, installation view www.camboard.de Tel. 07131 911201 ce-info@camboard.de Cable Cubby Products •...
  • Page 26 im Vertrieb von CAMBOARD Electronics Installaton, cont’d www.camboard.de Tel. 07131 911201 ce-info@camboard.de Cable Cubby Products • Installation 2-14 ® Fax 07131 911203...

  • Page 27: Chapter 3 • MaNtenance And ModFicatOns

    im Vertrieb von CAMBOARD Electronics Cable Cubby Products ® C hapter 3 Mantenance and Modficatons Removing.and.Replacing.the.Cable.Cubby Replacing.Cables.or.an.AAP Adding.an.Additional.Power.Module.(CC.600,.CC.800) www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...
  • Page 28 im Vertrieb von CAMBOARD Electronics Mantenance and Modficatons The Cable Cubby can be modified after installation to change cables, to replace an AAP, or to add a second power module. These modifications may require removing the cubby from the table. Removng and Replacng the Cable Cubby You may need to remove the cubby from the table in which it is mounted to replace cables or AAPs, to adjust the height...
  • Page 29 im Vertrieb von CAMBOARD Electronics Extron Cable Cubby 800 Pins Screw Clamp Phillips Head Screw (Secures AAP Shelf Assembly and Power Module.) Figure 3-1 — Removing the cubby and its shelves www.camboard.de Tel. 07131 911201 ce-info@camboard.de Cable Cubby Products • Maintenance and Modifications ®...
  • Page 30 im Vertrieb von CAMBOARD Electronics Mantenance and Modficatons, cont’d Cable Cubby 200 — Remove the screws at the four corners that secure the cubby to the table (figure 3-2). Figure 3-2 — Removing the Cable Cubby 200 Lift the enclosure from the table. The flanged edges of the top of the surface enclosure are sharp.
  • Page 31 im Vertrieb von CAMBOARD Electronics Cable Cubby 300, 600, and 800 — Snugly tighten the Phillips head screws on the screw clamps to secure the enclosure to the surface. Cable Cubby 300, 600, and 800 — Tighten the locking thumbscrews on the screw clamps to lock the clamp in position.
  • Page 32 AAP or no AAP space left at all. • Cable Cubby 600 and 800 international models — In general, you probably do not need replacement shelf brackets when you add an international module to...
  • Page 33 im Vertrieb von CAMBOARD Electronics Figure 3-4 shows typical configurations before and after you add a second power module to an international Cable Cubby 800. Before After UNSWITCHED 230~50/60Hz UNSWITCHED 230~50/60Hz UNSWITCHED 230~50/60Hz Four AAP Four AAP Three AAP Space Shelf Space Shelf Space Shelf Figure 3-4 —...
  • Page 34 UNSWITCHED UNSWITCHED 100-240V/ 5AMAX 100-240V/ 5AMAX Two AAP Two AAP Space Shelf Space Shelf Figure 3-5 — Cable Cubby 600 with second power module www.camboard.de Tel. 07131 911201 ce-info@camboard.de Cable Cubby Products • Maintenance and Modifications ® Fax 07131 911203...
  • Page 35 im Vertrieb von CAMBOARD Electronics Figure 3-6 shows typical configurations before and after you add a second US/Domestic power module to a US/domestic Cable Cubby 800 and suggests rack shelf configurations to replace the lost shelf space. Before After UNSWITCHED UNSWITCHED UNSWITCHED 100-240V/ 5AMAX...
  • Page 36 Secure the power module into position with the included four Phillips head screws (figure 3-7). Extron Cable Cubby 600 2 Screws ea. side Figure 3-7 — Installing the power module If desired, assemble and install replacement AAP shelf assemblies.

  • Page 37: Specifications

    im Vertrieb von CAMBOARD Electronics Cable Cubby Products ® A ppendx A Reference Informaton Specifications Cable.Cubby.Part.Numbers Included.Parts Replacement/Modification.Part.Numbers Routing.Template.Part.Numbers Top.Plate.Dimensions www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...
  • Page 38 im Vertrieb von CAMBOARD Electronics Reference Informaton Specficatons General Rack mount ........No, but furniture mountable Enclosure type ......Metal Enclosure dimensions Use the appropriate metal Extron routing template or refer to the surface cutout dimensions here before cutting a hole in the furniture or other surface.
  • Page 39 im Vertrieb von CAMBOARD Electronics Cable Cubby 300C Cable Cubby 300S Cable Cubby 300S Top plate (outer rim) ....5.130" W x 6.470" D (13.0 cm W x 16.4 cm D) Surface cutout (inside rim) ..4.625 ±0.0325" W x 5.970 ±0.0325" D (11.75 ±0.083 cm W x 15.16 ±0.083 cm D) Box (under surface) .....
  • Page 40 Vertrieb von CAMBOARD Electronics Reference Informaton, cont’d Cable Cubby 600 Cable Cubby 600 Top plate (outer rim) ....6.960" W x 6.960" D (17.68 cm W x 17.68 cm D) Surface cutout (inside rim) ..6.460 ±0.0325" W x 6.460 ±0.0325" D (16.41 ±0.083 cm W x 16.41 ±0.083 cm D)
  • Page 41 Small grommet ....0.31" (0.79 cm) Product weight Cable Cubby 200 ....2.5 lbs (1.1 kg) Cable Cubby 300S/300C .. 5.0 lbs (2.3 kg) Cable Cubby 600....9.0 lbs (4.1 kg) Cable Cubby 800....13.0 lbs (5.9 kg) www.camboard.de Tel. 07131 911201 ce-info@camboard.de...
  • Page 42 Cable Cubby 200 ....4 lbs (2 kg) Cable Cubby 300S ..... 8 lbs (4 kg) Cable Cubby 300C ..... 8 lbs (4 kg) Cable Cubby 600....12 lbs (6 kg) Cable Cubby 800....15 lbs (7 kg) Vibration ........ISTA 1A in carton (International Safe Transit Association) Listings, certifications ....

  • Page 43: Cable Cubby Part Numbers

    Cable Cubby 300C/domestic (black anodized finish) 60-527-01 Cable Cubby 300C international 60-713-nn Cable Cubby 600 Part number Cable Cubby 600 US/domestic (black anodized finish) 60-525-01 Cable Cubby 600 international 60-714-nn Cable Cubby 800 Part number Cable Cubby 800 US/domestic (black anodized finish)

  • Page 44: Included Parts

    im Vertrieb von CAMBOARD Electronics Reference Informaton, cont’d Included Parts The Cable Cubby includes the Cable Cubby Products ® manual and a selection of shelf brackets, cable pass through AAPs, grommets, and hole plugs that vary depending on the Cable Cubby model. See the table below for included parts: Large Small Small...
  • Page 45 im Vertrieb von CAMBOARD Electronics Replacement/Modficaton Part Numbers Power modules (CC 300, 600, 800) Part number Cable Cubby AC power module – USA 70-261-01 Cable Cubby AC power module – Swiss 70-262-01 Cable Cubby AC power module – Israel 70-388-01 Cable Cubby AC power module –...
  • Page 46 im Vertrieb von CAMBOARD Electronics Reference Informaton, cont’d AAP shelf brackets (CC 300, 600, 800) Part number Four-space AAP Cable Cubby bracket (set of 2) (figure A-2) 70-273-01 Three-space AAP Cable Cubby bracket (set of 2) (figure A-2) 70-272-01 Two-space AAP Cable Cubby bracket (set of 2) (figure A-2) 70-271-01 Single-space AAP Cable Cubby bracket (set of 2) (figure A-2) 70-392-01...

  • Page 47: Routing Template Part Numbers

    Template Part number Cable Cubby 200 routing template 70-384-01 Cable Cubby 300S/300C routing template 70-237-01 Cable Cubby 600 routing template 70-239-01 Cable Cubby 800 routing template 70-240-01 Top Plate Dmensons There are two preferred and recommended methods for cutting the table: either use the appropriate metal routing template (figure A-3 and chapter 2, Installation) and a router or use a hole saw (Cable Cubby 300C only).
  • Page 48 im Vertrieb von CAMBOARD Electronics Reference Informaton, cont’d C ut- O ut Template for Extron's Cable Cubby 200 4.394" (11.16 cm) .350" (1.90 cm) SURFACE CUT-OUT AREA = 3.155 0.0325" (8.01 0.083 cm) x 7.312 0.0325" (18.57 0.083 cm) 8.000" (20.32 cm) 7.312 0.0325"...
  • Page 49 im Vertrieb von CAMBOARD Electronics Cut-Out Template for Extron's Cable Cubby 300S 5.130" (13.0 cm) SURFACE CUT-OUT AREA = 6.470" 4.625 0.0325" (16.4 cm) (11.75 cm) x 5.970 0.0325" 5.970" (15.16 0.083 cm) (15.2 cm) 0.5" (1.3 cm) Cut surface material Cut-Out Radius: Top Panel out along this line.
  • Page 50 im Vertrieb von CAMBOARD Electronics Reference Informaton, cont’d Cut-Out Template for Extron's Cable Cubby 300C SURFACE CUT-OUT AREA = 6.000 0.0325" Dia. (15.24 0.083cm) User Access TEMPLATE IS NOT FULL SIZE. Figure A-6 — Cable Cubby 300C cut-out template www.camboard.de Tel.
  • Page 51 Cut surface material Top Panel Cut-Out Radius: out along this line. 0.25" (0.6 cm) User Access TEMPLATE IS NOT FULL SIZE. Figure A-7 — Cable Cubby 600 cut-out template www.camboard.de Tel. 07131 911201 ce-info@camboard.de Cable Cubby Products • Reference Information A-15 ®...
  • Page 52 im Vertrieb von CAMBOARD Electronics Reference Informaton, cont’d Cut-Out Template for Extron's Cable Cubby 800 8.360" (21.23 cm) 6.820" 6.320 0.0325" (17.32 cm) (16.05 0.083 cm) SURFACE CUT-OUT AREA = 7.860 0.0325"(19.96 0.083 cm) x 6.320 0.0325"(16.05 0.083 cm) 0.5" (1.3 cm) Cut surface material Top Panel...
  • Page 53 im Vertrieb von CAMBOARD Electronics Cable Cubby Products ® A ppendx B Packagng for Shpment www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...
  • Page 54 im Vertrieb von CAMBOARD Electronics Packagng for Shpment The Cable Cubby’s ultra-fine machined surfaces and moving parts make them vulnerable to damage caused by mishandling during shipment if they are improperly packaged. If, for any reason, you need to return a Cable Cubby to Extron, first contact Extron to obtain a return kit.
  • Page 55 im Vertrieb von CAMBOARD Electronics Disconnect and retain all cables, remove and retain the AAP shelf assembly(s) (CC 300, 600, 800) and remove the Cable Cubby from the table or desk. See Removing and Replacing the Cubby, steps 1 through 4, in chapter 3, Maintenance and Modifications.
  • Page 56 CC 600 and 800 only — Remove and discard the inner side foam sections of the cushion in the carton (figure B-4). If you are returning a Cable Cubby 600 model, this is the correct fit. Proceed to step 8.
  • Page 57 im Vertrieb von CAMBOARD Electronics Figure B-5 — Removing outer side foams If you will not install a replacement Cable Cubby in this location, remove and retain one of the small foam sections to the front or rear of the cubby opening in the cushion in the carton (figure B-6).
  • Page 58 im Vertrieb von CAMBOARD Electronics Packagng for Shpment, cont’d CC 300, 600, and 800 only — Stuff the foam section removed in step 8 into the screw clamp opening in the foam cushion in the carton. CC 300, 600, and 800 only — Lower the Cable Cubby, with the top closed, into the foam cushion in the shipping carton (figure B-7).
  • Page 59 im Vertrieb von CAMBOARD Electronics CC 200 only — Lower the Cable Cubby and foam into the shipping carton. Place the top foam pad, removed in step 4, on top of the Cable Cubby. Close the shipping carton and seal it with high quality shipping tape.
  • Page 60 im Vertrieb von CAMBOARD Electronics Packagng for Shpment, cont’d www.camboard.de Tel. 07131 911201 ce-info@camboard.de Cable Cubby Products • Packaging for Shipment ® Fax 07131 911203...
