Dimensions (continued)
Cable Cubby 300C — All regions (circular)
6.000 ±0.0325" (15.24 ±0.083 cm) diameter circle
Cable Cubby 600 — All regions
6.460 ±0.0325" W x 6.460 ±0.0325" D (16.41 ±0.083 cm W x 16.41 ±0.083 cm D)
Cable Cubby 800 — All regions
7.860 ±0.0325" W x 6.320 ±0.0325" D (19.96 ±0.083 cm W x 16.05 ±0.083 cm D)
Template Numbers
The routing template is reusable. Do not discard this template
when installation is complete. Save it for installing future surface
access enclosures of the same size.
No routing template is available for the HSA 822MS.
The following reusable routing templates are available from Extron at
no cost and their use is strongly encouraged for preparing the
mounting surfaces.
Template
HSA 200/222 US and Cable Cubby 300S/300C routing template 70-237-01
HSA 200/222 International routing template
HSA 400 US routing template
HSA 400 International routing template
HSA 402 US routing template
HSA 402 International routing template
HSA 822/HSA 822M (all regions) routing template
Cable Cubby 200 (all regions) routing template
HSA 200/222 US and Cable Cubby 300S/300C routing template 70-237-01
Cable Cubby 600 (all regions) routing template
Cable Cubby 800 (all regions) routing template
Extron Electronics, USA Extron Electronics, Europe
1230 South Lewis Street Beeldschermweg 6C
Anaheim, CA 92805 3821 AH Amersfoort
USA The Netherlands
714.491.1500 +31.33.453.4040
www.extron.com Fax 714.491.1517 Fax +31.33.453.4050
www.camboard.de
© 2006 Extron Electronics. All rights reserved.
CAMBOARD Electronics
Part number
70-237-02
70-189-01
70-189-02
70-190-01
70-190-02
70-191-01
70-384-01
70-239-01
70-240-01
Extron Electronics, Asia Extron Electronics, Japan
135 Joo Seng Road, #04-01 Kyodo Building
PM Industrial Building 16 Ichibancho
Singapore 368363 Chiyoda-ku, Tokyo 102-0082 Japan
+65.6383.4400 +81.3.3511.7655
Fax +65.6383.4664 Fax +81.3.3511.7656
Tel. 07131 911201
Fax 07131 911203
User's Guide
HSA Series and Cable Cubby
Routing Templates for Hideaway Enclosures
ce-info@camboard.de
Routing Template
68-625-01 Rev. D
10 06
