Input Buffer; Parallel Mode; Autofeed Signal - Compuprint 4051 User Manual

Input Buffer Size
I/F TIME-OUT
↑
→ or ←

INPUT BUFFER

↓

PARALLEL MODE

This function selects the input buffer size with one of the following values: 256, 4K, 8K, 16K or
32 K. The 16K and the 32K values do not allow the DLL. The most suitable value for the DLL
function is 256 (DLL).
Parallel I/F Mode
INPUT BUFFER
↑
PARALLEL MODE → or ←
↓

AUTOFEED SIGNAL

Parallel interface in Centronics monodirectional mode.
Parallel CX
Parallel interface in IEEE 1284 bidirectional standard mode.
Bidirectional
↑ or ↓
256 (DLL)
↑ or ↓
...
32K (No DLL) (*) ↑ or ↓
↑ or ↓
Parallel CX
↑ or ↓
Bidirectional (*)
46
