Top of Form (ToF)
BIDI. ALIGNMENT
↑
→ or ←
TOP OF FORM
↓
TEAR PERFO ALIGN
This function adjusts the top of the form in n/72 inch (4051/4051N plus models) or n/90 inch
(4056/4056N plus models). The values range between 0 and 792 (4051/4051N plus models) or
between 0 and 990 (4056/4056N plus models). At value selection level, the printer prints a
**x/72** string (4051/4051N plus models) or a **x/90** string (4056/4056N plus models), where
the x value indicates the current value corresponding to the current ToF position. If the value is
changed, the new value will be printed from its corresponding ToF position.
0/72 inches (4051/4051N plus models)
0/90 inches
(4056/4056N plus models)
...
792/72 inches (4051/4051N plus models)
990/90 inches (4056/4056N plus models)
See "Top of Form Adjustment" later in this manual.
↑ or ↓
↑ or ↓
↑ or ↓
↑ or ↓
↑ or ↓
64
