NETJet

Reference Numbers

It is important that you make a note of the printer server's unique ethernet
address (known as the Media Access Control or MAC address) and its serial
number. The figure below shows the locations of these numbers.
Although the following information is clearly printed on the unit, we suggest
you enter the numbers here for later reference.
MAC Address: 00-00-C9- ____ ____-____ ____-____ ____
Serial Number: ____ ____ ____ ____ ____ ____ ____
Next, enter the default printer server name. This name begins with a three
digit prefix unique to the type of printer server. The remaining digits are
taken from the last six characters of the MAC address, without the dashes.
For example, the prefix for the NETJet is NJA. Combined with a MAC
address such as 00-00-C9-01-A0-6A, the default server name for this printer
server will be NJA01A06A.
Serial Number
BCS1909
Figure 2-1: Location of Reference Numbers
Printer Server Installation 2-1
Ethernet
MAC Address
Faceplate
