A-4 Appendix
Parallel Connector Pinout
−
NETQue
−
NETQue Pro2
−
NETQue Token Ring
NOTE: This pinout must be maintained for bi-directional
Data Strobe
1
2 Data Bit 1
3 Data Bit 2
Data Bit 3
4
5 Data Bit 4
Data Bit 5
6
Data Bit 6
7
8 Data Bit 7
9 Data Bit 8
Acknowledge
10
11 Busy
Paper End
12
13 Select
printing to operate correctly.
Auto Feed
14
15 Error
16 Initialize
Select Inhibit
17
18 Logic Ground
Ground (Data Strobe Return Data Bit 1
19
Return)
Ground (Data Bit 2 & 3 Return)
20
21 Ground (Data Bit 4 & 5 Return)
22 Ground (Data Bit 6 & 7 Return)
Ground (Data Bit 8 & Acknowledge Return)
23
24 Ground (Busy Return & Paper End Return)
Logic Ground
25
