A-2 Appendix
Token Ring STP Pinout - Female-DB9
−
NETQue Token Ring
1
2
3
4
5
6
7
8
9
Serial Connector Pinout - Male DB9 (DTE)
−
NETQue
−
NETQue Pro2
−
NETQue Token Ring
1 DCD
2 RXD
3 TXD
4 DTR
5 GND
6 DSR
7 RTS
8 CTS
9 RI
Receive /R1
No Connection
No Connection
No Connection
Transmit/B5
Receive/G6
No Connection
No Connection
Transmit/09
Data Carrier Default
Receive Data
Transmit Data
Data Terminal Ready
Ground
Data Set Ready
Request To Send
Clear To Send
Ring Indicator
