MECHANICAL SYSTEM
B. Control Panel
1. Removing the Control Panel
1) Remove the copyboard glass.
2) Remove the upper left cover.
3) Open the front door.
4) Pull the open/close lever, and open the body.
5) Remove the right cover.
6) Remove the left cover.
7) Remove the four screws
inside cover .
1
2
Figure 4-104
8) Remove the screw
connectors (J801, J802, J803, J804); then,
remove the control panel
3
Figure 4-105
4–2
, and remove the
1
, and disconnect the four
.
4 3 4
COPYRIGHT © 1998 CANON INC.
3
Figure 4-106
C. Removing the Display
Panel
1) Remove the display panel
like.
1
Figure 4-107
CANON NP6621 REV.0 FEB. 1998 PRINTED IN JAPAN (IMPRIME AU JAPON)
5
3
using a pen or the
