S875WP1-E TPS
3.

Functional Architecture

This chapter provides a high-level description of the functionality distributed between the
architectural blocks of the Intel Server Board S875WP1-E.
3.1

Processor and Memory Subsystem

The Intel 82875P Memory Controller Hub (MCH) is one component of the Intel 875P chipset.
The MCH is a centralized controller for the system bus, the memory bus, the AGP bus, and the
accelerated hub architecture interface.
3.1.1

Processor Support

The Intel Server Board S875WP1-E supports a single Pentium 4 processor (in a µPGA478
socket) with a system bus of 400 /533 /800 MHz. The server board supports the processors
listed in Table 1.
Type
Pentium® 4 processor with
Hyperthreading (HT) Technology
Pentium 4 processor with
Hyperthreading Technology
Pentium 4 processor
CAUTION
Use only the processors listed above. Use of unsupported processors can damage the board,
the processor, and the power supply. See the Intel® Server Board S875WP1-E Specification
Update or go to http://support.intel.com/support/motherboards/server/S875WP1-E/
current list of supported processors for this board.
NOTE
Use only ATX12V or EPS12V compliant power supplies with the server board S875WP1-E.
ATX12V and EPS12V power supplies have an additional power lead that provides required
supplemental power for the Intel Pentium 4 processor. The board will not boot if you do not
connect the 20-pin (or 24-pin) and 4-pin (or 8-pin) leads of ATX12V or EPS12V power supplies
to the corresponding connectors.
Do not use a standard ATX power supply. The board will not boot with a standard ATX power
supply.
Revision 4.0

Table 1. Processor Support Matrix

Designation
2.40, 2.60, 2.80, and 3.0 GHz
3.06 GHz
2.0, 2.26, 2.4, 2.53, 2.6, 2.66, and 2.8
GHz
Functional Architecture
System Bus L2 Cache Size
800 MHz 512 KB
533 MHz 512 KB
400 / 533 MHz 512 KB
for the
5
