Table 56. Hardware Monitoring Submenu - Intel S875WP1LX Specification

S875WP1-E TPS
7.1.3.11 Hardware Monitoring Submenu
To access this menu, select Advanced on the menu bar, then Hardware Monitoring.
Maintenance Main
The submenu represented by Table 52 is used to view the hardware that is monitored. These
options can be viewed only, not changed.
Feature Options
No options
Processor Zone
Temperature
No options
System Zone 1
Temperature
No options
System Zone 2
Temperature
Processor Fan Speed No options
No options
VReg Fan Speed
Front Fan Speed No options
No options
+1.5Vin
No options
Vccp
No options
+3.3Vin
No options
+5Vin
+12Vin No options
Revision 4.0
Advanced
Security
PCI Configuration
Boot Configuration
Peripheral Configuration
Drive Configuration
Floppy Configuration
Event Log Configuration
Video Configuration
USB Configuration
Chipset Configuration
Fan Control Configuration
Hardware Monitoring
Remote Access Configuration

Table 56. Hardware Monitoring Submenu

Description
Displays processor zone temperature.
Displays system zone 1 temperature.
Displays system zone 2 temperature.
Displays the speed at which the processor fan is running.
Displays the speed for the rear fan.
Displays the speed for the front fan.
Displays voltage level.
Displays voltage level.
Displays voltage level.
Displays voltage level.
Displays voltage level.
BIOS Setup Program
Power Boot Exit
77
