GSM modem for the transmission of SMS messages: of
data logging and energy meters. The alarms can be sent
also automatically while the variables can be recalled by
means of special SMS question codes (see "How to use the
SMS" on page 52).
GSM kit type-tested for
model "TC35 TERMINAL" included GSM module, antenna
and 230 power supply.
Digital Outputs (on request)
To be used as alarms and/or retransmission of the energy,
gas, water metering and/or outputs remotely controlled by
means of the serial communication port. The outputs are
completely programmable independently of the type of
module being used.
Pulse outputs (on request)
Number of outputs: up to 4.
Type: from 1 to 1000 pulses programmable for K-M-G Wh,
K-M-G varh, open collector (NPN transistor).
V 1.2 VDC/ max. 100 mA, V
ON
Outputs connectable to total and/or partial meters.
Pulse duration: 220 ms (ON),
DIN43864.
Insulation: by means of optocouplers, 4000 V
output and measuring inputs, 4000 V
and power supply input.
Notes: the outputs can be open collector type or relay type
(for the relay output refer to the characteristics described in
the "alarm outputs" section).
Single phase connections
71
Technical features
72
WM4: Siemens kit (external)
30 VDC max.
OFF
220 ms (OFF) according to
RMS
83
between
RMS
between output
Filters
78
