Digital Outputs - CARLO GAVAZZI WM4-96 - PROGRAMMING Manual

Outputs / Other settings
The EURO/USA function allows the user to display
the date and time according to the EUROPEAN
(EURO, date: day/month/year; time: 24 hours) or
AMERICAN (USA, date: month/day/year; time: 12
hours / AM and PM) format.
S
F
S
F
S
using the
The instrument shows a window where the various slots
(OUT C0, OUT C1, etc.) and output channels (1, 2, etc.) are
shown. Select the desired slot using the
and confirm with
the module is not in the slot, the instrument displays NOT
AVAILABLE). To reset the choices and go back to the main
menu, press
Counters reset
43
and keys, then confirm with
S
to enter the output function menu (if
F
.
44

Digital Outputs

This function enables the
user to connect the type of digi-
tal output to the slot at the
beginning. The instrument indi-
cates if the module is not in the
slot with the message "NOT
AVAILABLE"; whereas if the
module is in the slot, the instru-
ment automatically goes to the
digital output menu, where the
user can set four different types of
output: PULSE, ALARM, DIAG-
NOSTIC, REMOTE CONTR. To
enter these functions, choose DIG-
ITAL OUTPUT from the main menu
55
45
