CARLO GAVAZZI WM4-96 - PROGRAMMING Manual page 16

16
Pass "998": display of the stored dmd variables
(Only if the RS232 + RTC module is present)
The stored dmd variables can be displayed by pressing
S
the key in any one of the measuring page (excluded the
"load profile" pages): when the instrument asks for the
display the values of the stored variables, the time (hours-
minutes-seconds) and the date (day-month) of storage.
"NOT AVAILABLE VALUE".
Pass "997": Reset of the Data Memory (only if the
RS232+RTC module is available)
It's possible to reset all the information stored in the data mem-
ory. To enter this function press the
measuring pages (excluded the "load profile" pages), when the
instrument asks for
confirm with
not to execute the reset.
Pass "996": Reset of the load profiles
It's possible to reset all the information relating to the
load profiles. To enter this function, press the
one of the measuring pages (excluded the "load profile
pages"), when the instrument asks for
enter the value "996" and confirm with
to confirm the reset, press
Energy Meters pages
11
Displaying of the variables
, enter the value "998": the instrument will
Use the
all the values; to exit press the
key. If the value has not been
stored, the instrument displays
S
, then press
8
and
S
, enter the value "997" and
S
to confirm the reset; press
S
F
not to execute the reset.
keys to scroll
key in any one of the
S
key in any
S
, then press
Inputs
F
F
again
