When the measuring input module (AQ1018-
AQ1019) is not present, the user can select only up
to 8 events (even though the menu remains
unchanged): from MAX 1 to MAX 4 and from MIN 1
to MIN 4. To select them, proceed as described above.
Display page
27
Programming
• MAX (logging of up to 12 differ-
ent variables MAX1 to MAX12), see
F
also: MIN MAX VALUES;
• MIN (logging of up to 8 different vari-
ables MIN1 to MIN8), see also MIN MAX
VALUES;
• D "diagnostics" (logging of up to 4 alarms:
from D1 to D4), see also: DIAGNOSTIC DIG-
ITAL OUTPUTS
• R "remote control" (up to 4 remotely con-
trollable outputs: from R1 to R4), see also:
REMOTE CONTROL DIGITAL OUTPUTS;
• A "alarms" (logging of up to 4 alarms:
from A1 to A4), see also: ALARM DIGITAL
OUTPUTS;
To use this function, select "EVENTS
SELEC." from the main menu using the
and
S
. Use the
where you want to enable the event (ON) or
disable it (OFF). The function of the
OFF-ON key is cyclical. To go back to the
main menu press
17
EVENTS SELEC.
This function allows the
user to enable the events
for data logging:
keys and confirm it pressing
and
F
.
