Phone Test Freq. (0302)
This setting determines how often the panel sends the automatic phone test
(see "Auto Phone Test" under
(or a pager). The phone test frequency can be set to report every 1 to 255 days.
Note
For UL 1635 listed installations, this feature must be set to 1.
Next Phone Test (0303)
This setting determines how many days (1-255) until the next automatic
phone test occurs. When setting up Phone Test Freq, Next Phone Test must be
set to accurately count the number of days left in the cycle before the next
phone test occurs. This setting should be the same or less than the Phone Test
Freq. setting.
Note
For UL 1635 listed installations, this feature must be set to 1.
Output Trip Time (0304)
This setting determines how long onboard and SnapCard outputs are activated
when tripped (if they are configured for a momentary response).
Activity Timeout (0305)
This setting determines when the system sends a "no activity" report. The
panel can be set to wait from 1-42 hours. If no user interaction or device acti-
vation occurs in that time, the panel sends a report to the central station.
Daylight Savings (0306)
This setting determines whether or not the panel clock automatically adjusts
for daylight saving time changes in spring and fall.
Programming the Panel
) to the central station
PHONE OPTIONS—GLOBAL
The following describes how to program the Timer settings that appear under
Timers-Global (Default=7 days)
¾
To set the Phone Test Freq:
1. With the display showing
(current setting), enter the number
nnn DAYS
of days (1-255). The display flashes the
entered setting.
ƒ
2. Press and the display shows the new set-
ting.
Timers-Global (Default=7 days)
¾
To set the Next Phone Test:
1. With the display showing
(current setting), enter the number
nnn DAYS
of days (1-255). The display flashes the
entered setting.
ƒ
2. Press and the display shows the new set-
ting.
Timers-Global (Default=4 sec.)
¾
To set the Output Trip Time:
1. With the display showing
(current setting), enter the num-
nn SECONDS
ber of seconds (1-12). The display flashes
the entered setting.
ƒ
2. Press and the display shows the new set-
ting.
Timers-Global (Default=24 hours)
¾
To set the Activity Timeout:
1. With the display showing
(current setting) enter the desired
nn HOURS
2-digit time value (1-42). The display flashes
the entered setting.
ƒ
2. Press and the display shows the new set-
ting.
Timers-Global (Default=on)
¾
To turn Daylight Savings off or on:
With the display showing
1.
(current setting), press 1 (off)
INGS OFF/ON
or 2 (on). The display flashes the entered
setting.
2. Press ƒ and the display shows the new set-
ting.
PHONE TEST FREQ
NEXT PHONE TEST
OUTPUT TRIP TIME
ACTIVITY TIMEOUT
DAYLIGHT SAV-
.
PARTITION 1
