Riser Card; Rack And Cabinet Mounting Options - Intel SC5650BCDP Technical Product Specification

Product Overview
A
C
E
G
I
K
2.5.3

Riser Card

The system supports one PCI riser card that has one PCI Express* Gen2 x8 connector with X8
link width that supports one half-length half-height (6.6 inches) riser card consuming 15 W or
less of power.
2.6

Rack and Cabinet Mounting Options

You can install the Intel
server cabinets. The system supports two rack mount options:
•
A fixed mount relay rack / cabinet mount kit that can be configured to mount the system
into either a 2-post or 4-post rack cabinet. (Product order code for the cabinet mount kit:
AXXBRACKETS.)
•
A basic slide rail kit designed to mount the chassis into a standard 19-inch by up to 30-
inch deep EIA-310D compatible server cabinet. (Product order code for the slide rail kit:
AXXBASICRAIL.)
Revision 1.5
®
Table 4. Intel Light-Guided Diagnostic LED reference
Description
Post-Code Diagnostic LEDs
System ID LED
System Fan 3 Fault LED
DIMM Fault LED
CPU 1 Fan Fault LED
System Fan 1 Fault LED
®
Server System SR1630BC in 19-inch wide by up to 30-inch deep
Intel order number E44588-005
Intel® Server System SR1630BC TPS
Description
B Status LED
D HDD LED
F 5 VSB LED
H System Fan 2 Fault LED
J CPU 2 Fan Fault LED
L DIMM Fault LED
11
