Intel® Server System SR1630BC TPS

Appendix C: POST Error Messages and Handling

Whenever possible, the BIOS outputs the current boot progress codes on the video screen.
Progress codes are 32-bit quantities plus optional data. The 32-bit numbers include class,
subclass, and operation information. The class and subclass fields point to the type of hardware
being initialized. The operation field represents the specific initialization activity. Based on the
data bit availability to display progress codes, a progress code can be customized to fit the data
width. The higher the data bit, the higher the granularity of information that can be sent on the
progress port. The progress codes may be reported by the system BIOS or option ROMs.
The Response section in the following table is divided into three types:
•
Minor: The message displays on the screen or in the Error Manager screen. The
system continues booting with a degraded state. The user may want to replace the
erroneous unit. The setup POST error Pause setting does not have any effect with this
error.
•
Major: The message is displayed in the Error Manager screen and an error is logged to
the SEL. The setup POST error Pause setting determines whether the system pauses
to the Error Manager for this type of error where the user can take immediate corrective
action or choose to continue booting.
•
Fatal: The message displays in the Error Manager screen, an error is logged to the
SEL, and the system cannot boot unless the error is resolved. The user must replace
the faulty part and restart the system. The setup POST error Pause setting does not
have any effect with this error.
Generator Sensor Type
ID Code
33h 0Fh
(BIOS (System
POST) Firmware
Progress)
Error Code
0012 CMOS date / time not set
0048 Password check failed
0108 Keyboard component encountered a locked error.
0109 Keyboard component encountered a stuck key error.
Fixed Media: The SAS RAID firmware can not run properly. The user should attempt to
0113
reflash the firmware.
0140 PCI component encountered a PERR error.
0141 PCI resource conflict
0146 PCI out of resources error
0192 Processor 0x cache size mismatch detected.
0193 Processor 0x stepping mismatch.
0194 Processor 0x family mismatch detected.
44

Table 26. SEL Format for POST Error Messages

Sensor
Type code
number
06h 6Fh
(BIOS (Sensor
POST Specific
Error) Offset)

Table 27. POST Error Messages and Handling

Error Message
Intel order number E44588-005
Appendix C: POST Error Messages and Handling
Event Data1 Event Data2
A0h xxh
(OEM Codes in (Low Byte of
Data2 & Data3) POST Error
Code)
Event Data3
xxh
(High Byte of
POST Error
Code)
Response
Major
Major
Minor
Minor
Major
Major
Major
Major
Fatal
Minor
Fatal
Revision 1.5
