Replacing a Fixed Fan (Intel
SC5400Base SC5400BRP only)
Note: This procedure applies only to the Intel
Chassis SC5400BRP configurations. The Intel
SC5400LXi ship with hot-swap fans.
1. Observe the safety and ESD precautions at the beginning of this book.
2. Power down the server and unplug all peripheral devices and the AC power cable.
3. Remove the chassis cover. For instructions, see
page
4. Disconnect the appropriate fan power cable from the server board.
5. Remove the 92-mm (see letter "A" in the following figure) or 120-mm (see letter
"B") fixed fan from its snap-in bracket.
6. Install new 92-mm or 120-mm fixed fan.
7. Connect fan power cable to the server board. See the Intel
Start User's Guide or User Guide for appropriate connection location.
8. Re-install the chassis cover. For instructions, see
page
9. Plug all peripheral devices and the AC power cable into the server and then power
up the server.
Intel® Server Chassis SC5400 User's Guide
16.
A
92-mm
Fixed Fan

Figure 14. Removing a Fixed Fan

17.
®
Server Chassis
®
Server Chassis SC5400 BASE and Intel
®
Server Chassis SC5400LX and
"Removing the Chassis Cover" on
B
120-mm
Fixed Fan
TP00991
"Installing the Chassis Cover" on
®
Server
®
server board Quick
23
