Installing and/or Removing a Server Board

Note: The server board you can install in your chassis depends upon the chassis model.
To install or remove a server board, do the following:
1. Observe the safety and ESD precautions at the beginning of this book.
2. Power down the server and unplug all peripheral devices and the AC power cable.
3. Remove the chassis cover. For instructions, see
page
4. Remove the front bezel assembly if it is installed. For instructions, see
the Bezel Assembly (Pedestal Only)" on page
5. Remove any PCI add-in boards that are present. For instructions, see
PCI Add-in Board(s)" on page
6. Remove the processor and memory air ducts. For instructions, see
Processor and Memory Air Ducts" on page
7. If installing a server board, refer to the User Guide and/or Quick Start User's Guide
that shipped with your Intel® server board for installation instructions. Use the
mounting screws, bumpers and standoffs (if necessary) that came with your chassis
to secure the server board to the chassis. Make sure the server board is properly
seated and then tighten the screws firmly, starting with the screws at the center of
the server board. Make cable connections per instructions in the Intel® server board
User Guide and/or Quick Start User's Guide.
8. If removing a server board, disconnect all cables connected to the server board.
Remove the mounting screws, starting with the screws at the center of the server
board. Remove the server board.
9. Re-install the processor and memory air ducts. For instructions, see
Processor and Memory Air Ducts" on page
10. If desired, install any PCI Add-in boards. For instructions, see
in Board(s)" on page
11. Re-install the front bezel assembly. For instructions, see
(Pedestal Only)" on page
12. Re-install the chassis cover. For instructions, see
page
13. Plug all peripheral devices and the AC power cable into the server.
14. Power up the server.
