Component Identification

Internal Components

A. Fixed Power Supply
B. Rear Serial B Connector
C. PCI Add-in Card Panel
D. Memory Air Duct
E. Processor Air Duct
F. Fixed Fans (2)
6
A
B
C

Figure 2. Internal Component Locations

D
E
F
G
G. Hard Disk Drive Cage Release
Mechanisms (2)
H. Front Panel Controls
I. 5.25-inch Device Bays
J. Front Panel USB/Serial B
K. Fixed Drive Cage 4-Drive (accessory)
L. Fixed Drive Cage 6-Drive
Intel® Server Chassis SC5400 User's Guide
I
H
J
K
L
AF000511
